Preparing The Machine For Operation; Installing The Ejection Chute; Attaching The Chassis - Stihl GHE 420 Manuel D'utilisation

Item Designation
P Flat head bolt
M6x16
Q Torx screw
M6x16
R M6 nut
S Installation tool
T Hexagon bolt
M14x130
•
Instruction manual
7. Preparing the machine for
operation
Risk of injury:
Carefully read the section entitled
"For your safety" ( 4.) and follow
all the safety instructions before
assembling the garden shredder.
Strictly observe all tightening
torques in the section "Preparing
the machine for operation" (
avoid damaging the machine.
Be sure to always wear
gloves. The blade cover
must be installed. (
Avoid damage to the machine.
When moving the basic unit into the
installation position shown, ensure
that the electric cable is not
damaged (pinched).
Place cardboard underneath the
machine to protect it from being
scratched.

7.1 Installing the ejection chute

● Move the basic unit (A) into the
installation position shown.
0478 201 9916 A - EN
1 Install the ejection chute extension
Qty.
● Attach the ejection chute extension (E),
1
engage the hooks (1) in the apertures
on the housing (2), turn downwards and
2
push on the retainers (3) at the side.
3 ● Screw in the screws (O) and tighten to
1 - 2 Nm.
1
1
2 Install the guiding plate
1
● Insert the guiding plate (F).
Ensure that the guides on the guiding
plate (4) are correctly located in the
guides of the ejection chute
extension (5).
● Fit screw (P) and tighten with nut (R).
● Screw in the screws (O) and tighten to
1 - 2 Nm.
3 Install the ejection chute plate
● Insert the ejection chute plate (G).
7.) to
● Screw in the screws (O) and tighten to
1 - 2 Nm.
● Fit screws (Q) and tighten with nuts (R).
Any slight tensions occurring in the
7.5)
ejection chute can be compensated by
readjusting the screws.

7.2 Attaching the chassis

● Move the basic unit (1) into the
installation position shown.
Only install the wheel carriers as
described, with the bent section
facing outwards.
The axle bore (2) must point to the
rear.
3
1 Install right and left wheel carrier:
● Position the right wheel carrier (C) on
the basic unit (1) as shown.
● Insert the screw (M) through the bore in
the wheel carrier and screw into the
centre bore using installation tool (S),
but do not tighten.
● Repeat this procedure on the left side.
2 Install the foot and plug:
● Push the foot (L) as far as possible onto
the wheel carrier (C) as shown.
The foot (L) engages in the wheel
carrier (C).
● Carefully drive the plug (K) as far as
possible into the wheel carrier (C).
● Repeat this procedure on the left side.
3 Mount the wheel on the axle:
● Push the retaining ring (N) as far as
possible into the groove in the axle (H).
● Push the wheel (I) onto the axle (H).
● Fit the wheel cap (J).
When installing, ensure that the
retaining ring (N) engages in the
groove in the axle (H) in order to
prevent the wheel from becoming
loose.
4 Installing the axle and wheel:
● Push the axle with pre-installed
4
wheel (3) through the bore (2) in the
wheel carrier, through the motor
cover (4) and through the bore (2) in the
second wheel carrier.
● Push the wheel (I) onto the axle (H).
● Push the retaining ring (N) as far as
possible into the groove in the axle (H).
● Fit the wheel cap (J).
