D2116
system. This does not apply to turbine tools, which
should be kept oil free.
Compressed air connection
• The machine is designed for a working pressure
of 6–7 bar = 600–700 kPa = 87–102 psi.
• Blow out the hose before connecting.
Maintenance
Rust protection and internal cleaning
Water in the compressed air, dust and wear particles
cause rust and sticking of vanes, valves, etc.
This can be prevented by flushing with oil (a few
drops), running the tool for 5–10 seconds and absorb-
ing the oil in a cloth. Protect the tool this way before
longer standstills.
Overhaul and lubrication
The tool should be checked regularly at six-monthly
intervals. If it is in heavy duty service or not running
properly, it should be taken out of service more often
for inspection.
Regarding instruction for dismantling and as-
sembly, see separate Service Manual.
The throttle valve, planetary gears, needle bearings
and ball bearings must be lubricated with grease
when the tool is dismantled for the regular overhauls.
Molykote BR2 Plus gives long intervals between
lubrications.
A
Clean the motor parts and apply a thin layer
of gleitmo 585 KC grease (180 g – Ordering
No. 4080 0871 80) onto the vanes and inner
surface of cylinder and end plates.
Assemble the motor and check that it is run-
ning free. Add two drops of oil through the
air inlet and run the motor (machine) at idling
speed for 5-10 seconds.
The strainer in the adapter should be cleaned regu-
larly to prevent choking with resultant decrease in
capacity
EN
© Atlas Copco Industrial Technique AB - 9836 3456 00
Safety and operating instructions
Lubricating guide for Grinder/Sander
(except turbine) and Drill
Brand General purpose
Bearings
BP Energrease LS-EP2
Castrol Spheerol EP L2
Esso Beacon EP2
Q8 Rembrandt EP2
Mobil Mobilegrease XHP 222
Shell Alvania EP2
Texaco Multifak EP2
Molycote BR2 Plus

Useful information

C Log in to Atlas Copco www.atlascopco.com
You can find information concerning our products,
accessories, spare parts and published matters on our
website.
Ergonomic guidelines
Consider your workstation as you read through this
list of general ergonomic guidelines and see if you
can identify areas for improvement in posture, com-
ponent placement, or work environment.
• Take frequent breaks and change work positions
frequently.
• Adapt the workstation area to your needs and the
work task.
• Adjust for convenient reach range by determin-
ing where parts or tools should be located to
avoid static load.
• Use workstation equipment such as tables and
chairs appropriate for the work task.
• Avoid work positions above shoulder level or with
static holding during assembly operations.
• When working above shoulder level, reduce
the load on the static muscles by reducing the
weight of the tool, using for example torque
arms, hose reels or weight balancers. You can
also reduce the load on the static muscles by
holding the tool close to the body.
• Make sure to take frequent breaks.
• Avoid extreme arm or wrist postures, particu-
larly for operations requiring a degree of force.
• Adjust for convenient field of vision by minimiz-
ing movement of the eyes and head during the
work task.
• Use the appropriate lighting for the work task.
• Select the appropriate tool for the work task.
Air lubrication
Energol E46
Arox EP46
Chopin 46
Almo oil 525
Tonna R32
Aries 32
See "Lubrication" in
Operating instruc-
tions
