OPTION 2:
Maximum Equivalent Vent Length Tables:
Determine the number of 90 degree elbows in the vent system. (two 45 degree elbows count as one 90 degree elbow.)
Refer to the tables below to find the maximum vent length based on the number of elbows and termination style.
Total Equivalent Vent Length (Intake/outlet) for Twin Pipe 3" PVC/CPVC
Maximum Vent Length
Termination Type
Termination Equivalent Length in feet
(meters) (Already factored into the straight
pipe lengths below)
# of 90° Elbows (each: 5 equivalent feet)
Total Equivalent Vent Length (Intake/outlet) for Twin Pipe 4" PVC/CPVC
Maximum Vent Length
Termination Type
Termination Equivalent Length in feet (meters)
(Already factored into the straight pipe lengths
below)
# of 90° Elbows (each: 5 equivalent feet)
**SW 1 in DIPSW 1 is "OFF" for lengths greater than or equal to 21 feet
Maximum vent lengths are specific to the fuel type of the tankless water heater. It is imperative when
performing equivalent vent length calculations that the gas type be taken into consideration.
24
0
1
2
3
4
5
6
0
1
2
3
4
5
6
41 Feet
IPEX or Royal
Snorkel
Concentric Vent
Termination
Kit
20 (6.1) 15 (3.0)
Max. straight pipe vent length in feet (meters)
21 (6.4) ** 26 (7.9) **
16 (4.9) ** 21 (6.4) **
11 (3.4) ** 16 (4.9) **
6 (1.8) ** 11 (3.4) **
- 6 (1.8) **
- 1 (0.4) **
-
IPEX Concentric
Vent Kit Termination
20 (6.1)
Max. straight pipe vent length in feet (meters)
80 (24.4) ** 85 (25.9) **
75 (22.9) ** 80 (24.4) **
70 (21.3) ** 75 (22.9) **
65 (19.8) ** 70 (21.3) **
60 (18.3) ** 65 (19.8) **
55 (16.8) ** 60 (18.3) **
50 (15.2) ** 55 (16.8) **
ATTENTION
KCM Series Manual
Side Wall Tee
Termination
5 (1.5)
36 (11.0) **
31 (9.4) **
26 (7.9) **
21 (6.4) **
16 (4.9) **
11 (3.4) **
- 6 (1.8) **
100 Feet
Snorkel Side Wall Tee
Termination
15 (3.0) 5 (1.5)
95 (29.0) **
90 (27.4) **
85 (25.9) **
80 (24.4) **
75 (22.9) **
70 (21.3) **
65 (19.8) **
IPEX or Royal
Low Profile
Termination
5 (1.5)
36 (11.0) **
31 (9.4) **
26 (7.9) **
21 (6.4) **
16 (4.9) **
11 (3.4) **
6 (1.8) **
Low Profile
Termination
5 (1.5)
95 (29.0) **
90 (27.4) **
85 (25.9) **
80 (24.4) **
75 (22.9) **
70 (21.3) **
65 (19.8) **
