R75LSi
R94LSi
The VB series (R75LSi, and R94LSi) are certified for
installation in manufactured (mobile) homes.
Register your product at www.rinnairegistration.com or
call 1-866-RINNAI1 (746-6241)
ANS Z21.10.3
●
CSA 4.3
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING
result causing property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in
•
your building.
Immediately call your gas supplier from a neighbor's phone.
•
Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire
•
department.
- Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
Direct Vent Tankless Water Heater
Operation and Installation Manual
R75LSi ................ REU-VB2528FFUD-US
R94LSi ................ REU-VB2735FFUD-US
R98LSi ................ REU-VA3237FFU-US
R98LSi-ASME .... REU-VA3237FFU-ASME
FOR INDOOR APPLICATIONS ONLY
Table of Contents ..................... 2
Operating Instructions ............... 5
Maintenance ........................... 12
Error Codes ............................ 13
Installation Instructions ........... 17
Consumer Support .................. 46
French Version ....................... 48
If the information in these instructions is not
followed exactly, a fire or explosion may
