Section 5. Operating
Instructions
NOTE The user interface is located inside the control/
power center. To access the control panel, open
the door to the control/power center.
See Figure 17.
Figure 17. User Interface
5.1

User Interface Controls

Pressing the down arrow button
Chlorine
Production A or the up arrow button B
will change the CHLORINE
Rate
PRODUCTION RATE in 5%
Adjustment
increments. Generally, adjustments
to production should be made in
10% increments.
In the PureLink
adjustments to the chlorine
production rate can be made from
either the AquaLink
panel or from the power center user
interface.
|
Zodiac Nature Fusion Soft Installation and Operation Manual
® 2®
system,
TM
RS control
®
ENGLISH
Salinity Press the SALINITY button C to
check the salinity of the water in
pool.
Boost Press and hold the POOL TEMP
-BOOST- button D for 10 seconds
to enter the Boost mode (Note 'bo'
will flash intermittently). Boost can
be used to set chlorine production
to maximum (100%) for 24 hours
of operation. After 24 hours of
chlorinator run time, chlorine
production will return to previous
setting. To clear the Boost mode,
press and hold the POOL TEMP
-BOOST- button D again for 10
seconds.
NOTE When a pool pump timer
Press the POOL TEMP -BOOST-
Temperature
button D to check the pool
water temperature. Temperature
measurements can be displayed in
either Fahrenheit or Celsius. For
more information, see Section 8,
Temperature Conversion.
Page 29
is used to limit chlorinator
run time, the 24 hours will
only count down when the
chlorinator is on.
