Product Description - EVBOX WALL BOX Manuel D'installation

Part number: 9835663080

Product description

Product configuration
The table below contains the available product configurations for the wall box. This manual covers
the wall box versions with socket and shutter. For wall box models with with fixed charging cable (ref-
erence number 9835662980, 9835663180 and 9835662780), see the installation manual for wall box.
PSA
PSA PSA
reference description
number
9835663080 WALL BOX
7,4 kW S
9835662680 SMART
WALL BOX
22 kW S
9835662980 WALL BOX
11 kW C
9835663180 SMART
WALL BOX
7,4 kW C
9835662780 SMART
WALL BOX
11 kW C
INSTALLATION_WALL_BOX_SOCKET_PSA_B2C_MERGED.indd 7
Power
Installation Maximum
output
power
1P+N+PE - 7,4 kW
32 A - 230
Vac
3P+N+PE 22 kW
- 32 A -
230/400 Vac
3P+N+PE 11 kW
- 16 A -
230/400 Vac
1P+N+PE - 7,4 kW
32 A - 230
Vac
3P+N+PE 11 kW
- 16 A -
230/400 Vac
Vehicle connections
(IEC 62196)
Fixed cable Socket
6m. with type
charge 2 with
plug type 2 shutter
- •
- •
• -
• -
• -
EN
Connectivity
Auto- Back-
start end
default ready
• -
- •
• -
- •
- •
