12.0 Technical Data

Overall width:
With standard wheels including handrims, close mount:
min = 540mm, max = 720mm
Overall height:
min = 750mm, max = 950
Overall length including foot rests:
min = 935mm, max = 1075mm.
Maximum load: 125kg. (100kg with handbike axle).
Weights in kg:
min = 11kg, max = 15kg
Heaviest part (Wheel) = 2.2kg
Footrest = 0.8kg
Side Guard Assembly = 1.3kg
Wheel (each) = 2.2kg
ALSO SEE PAGE 6
ADDITIONAL NOTES
In Accordance with EN12183: 2009 all there listed parts (seat -
back upholstery, arm pad, side panel...) are fire resistant as per
EN1021-2 .
The Dynamic safe slope is dependant on the chair configuration,
the users abilities and the style of riding. As the users abilities and
style of riding cannot be predetermined then the max safe slope
cannot be determined. Therefore this must be determined by the
user with the assistance of an attendant to prevent tipping. It is
strongly recommended that inexperienced users have Ant-tips
fitted.
The wheelchair conforms to the following standards:
a) Requirements and test methods for static, impact and fatigue
strengths (ISO 7176-8)
b) Requirements for resistance to ignition in accordance with ISO
7176-16 (EN 1021-1)
Life R Rev.D

13.0 Torque

Unless otherwise advised, the torque for M6 screws is 7 Nm.
Please refer to page 7 for detaials
