[Log dAtA]: Procedure to pre-set and start the data-logging.
1.
Press SET until the display shows [SEt LoG] and press CAL to
continue.
2.
Select [Log dAtA] with
return.
3.
Choose with
... etc. Select the desired mode and press CAL.
4.
The display shows e.g. [dt=100]. Select the desired time interval
(0...9999 s) between the data-logging, with
5.
This step is skipped unless manual data-logging is chosen. Pre-set
the time-interval (dt) to zero and press CAL to continue (point 6 is
skipped).
6.
The display shows e.g. [n=40]. Select the desired number of values
(1...500) to be data-logged with
7.
The display shows [StArt ?]. Press CAL to start the data-logging
according the previous settings (a blinking [L] appears) or press
MODE to return. After the last value has been data-logged the display
will show [End LOG]. When manual data-logging has been selected,
press PRINT to put a next measurement into memory. In the
meantime the display shows the logging-number e.g. [LOG 7]. Press
SET to return.
[Cnt LoG]: Procedure to continue with a next series of measure-
ments, without erasing the previous data-logging.
1.
Press SET until the display shows [SEt LoG] and press CAL to
continue.
2.
Select [Cnt LoG] with
capacity left! Press CAL to continue to continue with a next series of
measurements, without erasing the previous data-logging.
3.
Press SET to return.
[LSt dAtA]: Permits to view the stored values on the display.
1.
Press SET until the display shows [SEt LoG] and press CAL to
continue.
2.
Select [LSt dAtA] with
3.
The display shows the first data-logged value in memory (a blinking
[n] appears). Press
4.
While pressing HOLD the corresponding date is shown.
5.
While pressing RES the corresponding time shown.
6.
Press PRINT to send the recalled data to a printer.
7.
Press SET to return.
[Prt dAtA]: Permits to send the stored values to a printer or
computer.
1.
Press SET until the display shows [SEt LoG] and press CAL to
continue.
2.
Select [Prt dAtA] with
3.
The display shows [PrintinG] while all data-logged values, including
corresponding dates and times, are sent to the RS232 output in the
following format, compatible with EXCEL™, LOTUS 123™,....The
columns are separated by a TAB character:
or
and press CAL to continue or SET to
or
between [LOG PH1], [LOG PH2],..., [LOG µS],
or
or
provided the memory has enough
or
and press CAL.
or
to view all other values.
or
and press CAL to print the data.
or
and press CAL.
and press CAL.
Logging data
Adding data
Recalling data
Printing data
