AUDIO SETTINGS
[SOUND EFFECT]
[SPACE ENHANCE] (Not applicable for FM/AM source.)
[SMALL]/[MEDIUM]/[LARGE]: Virtually enhances the sound space. ;
[OFF]: Cancels.
[SND RESPONSE] [LEVEL1]/[LEVEL2]/[LEVEL3]: Virtually makes the sound more realistic. ;
[OFF]: Cancels.
[SOUND LIFT] [LOW]/[MIDDLE]/[HIGH]: Virtually adjusts the sound position heard from
the speakers. ; [OFF]: Cancels.
[VOL LINK EQ] [ON]: Boosts the frequency to reduce the noise heard from outside the car
or running noise of the tyres. ; [OFF]: Cancels.
[K2 TECHNOLOGY] (Not applicable for FM/AM source, SIRIUS XM source and AUX source.)
[ON]: Improves the sound quality of compressed music. ; [OFF]: Cancels.
Speaker output settings
[SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY]) (page 25)
Select the output setting for the speakers [SPK/PRE OUT], based on the speaker
connection method.
Connection via lineout terminals
For connections through an external amplifier. (Page 41)
KD-X360BTS:
Setting on
[SPK/PRE OUT]
FRONT
[REAR/REAR] (default) Front speakers
output
[REAR/SUB.W] ( Not available )
[SUB.W/SUB.W] Front speakers
output
26
ENGLISH
Audio signal through lineout terminal
REAR
Rear speakers output Subwoofer output
( Not available ) ( Not available )
L (left): Subwoofer output Subwoofer output
R (right): (Mute)
KD-X260BT/KD-SX25BT:
Setting on
[SPK/PRE OUT]
[REAR/REAR]
[REAR/SUB.W] (default) Subwoofer output
[SUB.W/SUB.W]
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page 40)
Setting on
[SPK/PRE OUT]
[REAR/REAR]
[REAR/SUB.W]
[SUB.W/SUB.W]
If [SUB.W/SUB.W] is selected:
– [120HZ] is selected in [SUBWOOFER LPF] and [THROUGH] is not available.
(Page 28)
– [POSITION R02] is selected in [FADER] and selectable range is [POSITION R15] to
[POSITION 00]. (Page 25)
SW
Audio signal through lineout terminal
REAR/SW
Rear speakers output
Subwoofer output
Audio signal through rear speaker lead
L (left)
Rear speakers output Rear speakers output
Rear speakers output Rear speakers output
Subwoofer output
R (right)
(Mute)
