4021 PARTS FOR MAINTENANCE

Qty. Description
1 DISPLAY ASSEMBLY
1 MAIN BOARD TO JUNCTION BOX LOAD CELL CABLE
1 DISPLAY SUPPORT
1 SMALL REAR COVER FOR DISPLAY SUPPORT
1 HANDLE
2 SOCKET HEAD CAP SCREW M6 1.0 x ½
1 HANDRAIL
1 ADAPTER HOLDER
11 SHEET METAL SCREW #8 x ½
1 HEALTH O METER LABEL
1 MODEL LABEL
4 SOCKET HEAD CAP SCREW M8 1.25 x ¾
1 BASE ASSEMBLY (PLATFORM ASSEMBLY)
2 WHEEL ASSEMBLY
1 CONNNECTOR BOARD
1 PHILLIPS PAN HEAD SCREW #6 x ¼
1 BOTTOM COVER
4 PLASTIC FOOT ASSEMBLY
8 SOCKET HEAD CAP SCREW NC5/16-18 x ¾
4 LOAD CELL
1 MAT
12 SOCKET HEAD CAP SCREW M8 1.25 x ¾
12 M8 WASHERS
4 PLASTIC CABLE CLIP WITH ADHESIVE BACK
1 LEFT SIDE HANDRAIL
1 RIGHT SIDE HANDRAIL
1 FRONT COVER FOR DISPLAY SUPPORT
2 SOCKET HEAD SCREW M10 1.5 x 1½
6 PHILLIPS PAN HEAD SCREW M4
1 REAR COVER
1 POWER ADAPTER 31 120V-240V
* See page 12 for a detailed view of parts by number.
Part No. Key
No.*
B1109401-0 1
B2033701-0 2
B2266901-0 3
B3822601-0 4
B3822901-0 5
5a
B3824021-0 6
B3817001-0 7
8
9
10
11
B3822001-0 12
B2267201-0 13
B2138901-0 14
15
B3822401-0 16
B2266701-0 17
18
B1304202-0 19
B3823001-0 20
21
21a
B401305 22
23
24
B3822501-0 25
26
27
B3822701-0 28
ADPT31 29
