USER MANUAL
7 MAINTENANCE
7.A SAFETY INSTRUCTIONS
The MACH 45 UNI is using two types of power sources: electric and pneumatic. It is essential for your safety
to make sure that both of them are disconnected prior to make any maintenance . Please refer to instructions
below prior to perform any maintenance.
Unplug the machine
from the electrical
supply
If using compressed air to clean some parts, wear safety glasses. It is even recommended to use a vacuum to
7.B MAINTENANCE PLAN
7.B.a Daily maintenance:
It is recommended once a day to clean the table surface with a clean cloth and make sure there is no debris in the distributor
head. If some glue is remaining in the distribution block, then perform procedure:
7.C REMOVING THE DISTRIBUTOR HEAD page (43)
7.B.b

Every 6 months:

Every 6 months a maintenance should be performed to ensure proper function of the machine, perform the following procedure
to do it:
7.C REMOVING THE DISTRIBUTOR HEAD page (43)
7.D OPENING THE SIDE PANELS page (43)
7.E REMOVING THE HAMMER page(44)
7.F LUBRICATING THE DISTRIBUTOR HEAD page (44)
7.H RESETTING THE MAINTENANCE ALARM page (45)
7.I LUBRICATING THE HORIZONTAL COLUMNS page (45)
7.J TESTING THE SAFETIES OF THE MACHINE page (46)
Figure 7-1
clean the machine rather than compressed air that will spray dust everywhere.
All maintenance and control operations must be carried out by skilled maintenance staff.
Rotate red button in
EXH position.
Unplug the machine
from pneumatic
source.
Install a locker to
ensure nobody will
turn back on the
machine while you
will be performing
the m aintenance.
MACH 45 UNI
Figure 7-2
42
