USER MANUAL
Touch the value of
the corresponding
position. A keyboard
will be displayed to
allow you to enter
the desired position
in millimeter.
Once you have
entered the desired
position, press the
Enter button to
validate it. The
keyboard will turn
off.
CLR button can be
used to clear the
value if a mistake
was done, DEL
erases the last digit
entered.
If a second position
is needed, touch the
number
corresponding to the
position to be
programmed and
proceed in the same e
way to enter the he
desired values.
Use the two arrows
to move the head in
one way or the other
until you reach the
required position.
The value
entered
millimeters
should be measured
from the rebate.
Figure 5-7
Using Using the the
method, touch
amount of wedges to
be inserted in the
selected position and
enter the
value.
Figure 5-9
Instead of measuring
the position
entering it with the
keyboard,
possible to move the
shooting head step
by step
required
This allows to check
immediately that the
position of the top
clamp will be steady.
Touch the number of
Figure 5-11
the
position.
Figure 5-13
to be
is in
and
same same
the
desired
and
it is
to the
position.
required
MACH 45 UNI
Figure 5-8
Figure 5-10
Figure 5-12
22
