HELMET AND HEADGEAR ASSEMBLY
1. Insert screws (A) through the openings in the headgear (D).
2. Insert the headgear (D) into the helmet shell (F) as shown in figure 1 and push the screws (A)
through the rectangular openings in the helmet shell.
3. Put the tilt adjustment (B) on the right side between the screw (A) and helmet shell (F). Make
sure that a small pin is fixed in one of the three holes in the helmet shell. Choose the right hole
for your maximum comfort.
4. Tighten the nuts (C) on the screws (A). Before adequately tightening them, place the headgear
at the most comfortable distance from the filter opening by adjusting the possition of headgear
within the two rectangular holes in the helmet shell.
5. The headgear size (D) can be adjusted by turning the rear wheel (E) in order to fit any head
size. Press the wheel and hold it while turning, release the wheel when reaching the position
of maximum comfort, so that it will lock in the required position.
C A
D
E
The headgear is equipped with a replaceable sweatband. Sweatbands are available
through your local dealer.
A B C
F
Figure 1
