BRUSH DECK
KIT ITEM REF. NO.
1 9100000875
K1 2
K2-3 3
K2 4
5 9100001191
K3 6
7 9100001186
K2 8
K3 9
K3
10
K3
11
K3 12
K3 13
K3 14
K3 15
K2 16
K3 17
18 9100000797
K3 19
20 9100000868
21 9100000869
22 9100000870
23 9100000871
24 9100000872
25 9100000873
26 9100000874
27 9098376000
K3 28
29 9100001163
K3 30
K2 31
32 9100001132
K3 33
K1 34
K1 35
K3 36
K3 37
K1 38
K1 39
K1 40
K3 41
[K1] 909 6887 000
[K2] 9100001175
[K3] 9100001176
01/2015
QTY DESCRIPTION
1 KEY 5X5X30 DIN6885 2 PCS SET
1 SCREW M8X30 UNI5739
7 NUT SELFLOCKING LOW M8 UNI7474 SS
20 WASHER M8 UNI6592 SS
1 VIBRATION-DAMPING M6 60SH PKD
5 WASHER M6 UNI8842A SS
1 SCREW M6X20 UNI5739 SS 10 PCS SET
8 SCREW M8X25 UNI5739 SS
4 SCREW M6X25 UNI5739 SS
4 WASHER 6.6X24X2 UNI6593 SS
3 WASHER 8.5X32X2 SS
1 SCREW M8X16 UNI5739 SS
1 WASHER NORD LOCK M6 DIN25201
3 WASHER M8 UNI8842A SS
1 SCREW M6X16 UNI5739 SS
4 WASHER NORD LOCK M8
1 SCREW 3.5X16 SELF THD PAN PHIL F PLASTIC
1 HOSES BRUSH DECK KIT
1 CLAMP 6.6X 7
1 VIBRATION DAMPING M8 60SH 2 PCS SET
1 COVER SOLUTION HOSE SUPPORT PKD
1 SOLENOID VALVE 24V PKD
1 HUB BRUSH PKD
1 PLATE BRUSH DECK HOLDER PKD
1 DECK BRUSH PKD
1 REDUCTION GEARMOTOR 450W 24V PKD
1 CARBON BRUSHES KIT 4 PCS
2 SCREW PAN HD SELF 4x12 SS
1 ARM BRUSH DECK LIFTING 4 PCS SET
2 SCREW M8X20 UNI5739 SS
8 BUSHING D.8.1X13X4.3
1 HARNESS BRUSH MOTOR PKD
1 SPACER D.6X12X8.5
1 WASHER 15
1 WASHER 8X24X2 FLAT ISO7093
1 NUT SELF L. M6 UNI7474 SS
4 WASHER 6X18X1.5 UNI6593 SS
1 ROLLER BUMPER D.160 BLACK
1 CAP. BLACK
1 SPACER 9X15X13
2 TIE CABLE 4.8X500 BLACK
1 ROLLER BUMPER KIT
1 HARDWARE BRUSH DECK LIFTING ARMS KIT
1 HARDWARE BRUSH DECK KIT
RA40 - 9100000394
PARTS LIST
