SQUEEGEE SYSTEM
KIT ITEM REF. NO.
K1 1
K1 2
K1 3
K1 4
5 9100000862
6 9100000747
K1 7
8 9100000791
9 9097637000
10 9100000559
11* 9100000810
11* 9100000490
11* 9100000060
K1 12
13 9100000864
K1 14
K1 15
16 9100000865
17 9100000866
K1 18
K1 19
K1 20
21 9100000867
K1 22
[K1] 9100000748
01/2015
QTY DESCRIPTION
2 WASHER 6X18X1.5 UNI6593 SS
1 NUT SELFLOCKING LOW M8 UNI7474 SS
1 WASHER 8X24 UNI6592 SS
6 WASHER 5X15X1.2 UNI6593 SS
1 KNOB LOBES M8 FEMALE PKD
1 SQUEEGEE 730MM/29 PRE-ASSEMBLED PKD
3 SPACER 5.1X8X28.5 PLASTIC
2 KNOB M8X30 THD STUD SS PKD
1 SQUEEGEE FIXING KIT
3 WHEEL D.51 GREY PKD
1 BLADE SQUEEGEE 740MM 29 GUM KIT
1 BLADE SQUEEGEE 730MM 29 PU KIT
1 BLADE SQUEEGEE 730MM 29 RED GUM KIT
1 SCREW M5X50 UNI5737 SS
1 STRAP ELASTIC F REAR SQUEEGEE BL. PKD
3 NUT SELFLOCKING LOW M5 UNI7474 SS
2 SCREW M5X45 UNI5737 SS
1 STRAP FRONT SQUEEGEE BLADE PKD
1 SUPPORT SQUEEGEE WHEEL PKD
1 SCREW M8X50 HEX HD F/THD SS ISO4017
1 NUT HEX M8 ISO4035 SS
2 SCREW 5X35 SELF THD TAPPING AW20 BLACK
1 GUIDE WHEEL 2 PCS SET
2 NUT HEX M8 UNI5588 SS
1 HARDWARE SQUEEGEE KIT
RA40 - 9100000394
PARTS LIST
