ACTUATORS
KIT ITEM REF. NO.
K2 1
K1 2
K1 3
K2 4
5 9100001126
6 9100001131
K2 7
K1 8
9 9100001103
10 9100001133
K2 11
K2 12
K1 13
[K1] 9100001172
[K2] 9100001173
01/2015
QTY DESCRIPTION
2 NUT.M8
5 WASHER M6 UNI6592
5 SCREW M6X12 UNI5931 SS
2 SCREW M8X50 UNI5931 THREADED TOTALLY
1 SUPPORT DECK ACTUATOR PKD
1 ACTUATOR 24V DC STROKE 98MM PKD
1 WASHER M8 UNI6592
2 SCREW CYL HD 5X20 SELF L. PLASTOFAST
1 SUPPORT SQUEEGEE ACTUATOR PKD
1 ACTUATOR 24V DC STROKE 77.5MM PKD
1 PIN SQUEEGEE ACTUATOR
1 PIN SPLIT 2X50 UNI8833
1 SCREW M6X12 UNI5931
1 HARDWARE ACTUATOR SUPPORT KIT
1 HARDWARE ACTUATOR KIT
RA40 - 9100000394
PARTS LIST
