Guidance displays

Once a route has been calculated, visual
guidance navigates you to the destination along
with audio guidance.
Information on map tool menu
1 2 3
1 To show/hide tool menu.
2 To switch the map direction (north up/
heading up) of the 2D map.
3 To switch to map scrolling mode.
4 To view TMC information.*
5 To view detailed GPS information.
6 Indicates battery condition.
* NV-U70T/U50T only.
Lights up in bright orange during reception.
Lights up in dark orange during no reception.
2D map display
Straight-ahead driving
A
B C D
Approaching an intersection
G
4 5 6
E F
Approaching an intersection (closer)
H
Next guidance immediately after intersection
I
A Current position
B Distance to next turn
C Next direction
D Current street name
E Next street name
F ETA (Estimated Time of Arrival)/Distance to
destination
G Next turn instruction
H Bar indication of distance to next turn
I Instruction after next
3D map display
You can set the 3D map display in the setting
menu (page 16).
View route display
You can view the entire route to the destination.
To display, from the top menu, select "Route" c
"View route."
continue to next page t
15
