Right Side Panel (Control Panel)
MENU button
/FILE SELECT button
FLANGE BACK (flange focal length)
adjustment ring
/BLACK button
/
WHITE button
BARS button
ENTER button
button
MENU button
Displays the MAIN menu on a monitor screen. Press again
to exit the menu. When a setting menu is displayed, press
this button to return to the MAIN menu.
For menu operations, see "Operation through Menus" on page
14.
/BLACK (black balance) button
While the menu is displayed: Moves the menu cursor
upward. Also use this button for an AE window setting,
etc.
While the normal screen is displayed: Activates the
automatic black balance adjustment.
/
WHITE (white balance) button
While the menu is displayed: Increases the setting value or
changes the setting. Also use this button for an AE
window setting, etc.
While the normal screen is displayed: Activates the
automatic white balance adjustment when MODE is set
to AWB in WHITE BALANCE menu.
9
Chapter 1 Overview
(GB)
