Adjusting and Setting with Menus
GENERAL menu
Sets the general items.
<GENERAL>
>CCD MODE
SHADING COMP.
TRIGGER
NEGA
FLICKER CANCELLER
Select
Setting items in the GENERAL menu
Setting item Contents of setting
CCD MODE Selects the CCD read-out mode.
SHADING Eliminates color at the top and bottom of
COMP. the screen.
TRIGGER Sets the polarity when connecting a slave
unit to synchronize with a stroboscope.
NEGA Reverses the output image to negative.
FLICKER Reduces flicker when SHUTTER is set to
CANCELLER CCD IRIS or OFF.
26
(GB) Chapter 2 Operation
[A]
FIELD
OFF
OFF
OFF
OFF
Back
MENU
Ref. page
26
26
27
27
27
CCD MODE
Selects the CCD read-out mode.
Selection Function
FIELD Accumulates charges in field units. Use to shoot a moving
object.
FRAME Accumulates charges in frame units. Provides the image
with the highest possible vertical resolution. Use to shoot
a still object.
SHADING COMP. (Shading compensation)
Eliminates green or magenta color which may appear at the
top or bottom of the screen, when the camera is used with an
optical instrument.
Selection Function
OFF Color elimination does not function.
ON If green or magenta color appears at the top or bottom of
the screen when the camera is attached to a microscope,
etc., select this setting.
When SHADING COMP. is set to ON, LEVEL is displayed.
Adjust while watching the screen so that the color is
eliminated. Adjustable range is from –127 to +127.
Adjusting Effect
direction
+ Green at the top and magenta at the bottom will be
eliminated.
– Magenta at the top and green at the bottom will be
eliminated.
