RGB SYNC
Adds a sync signal to the G signal or R, G and B signals
output from the RGB/SYNC connector.
Selection Function
OFF No sync signal is added to an output signal.
G Adds a sync signal to the G signal output from the
RGB/SYNC connector.
RGB Adds sync signals added to the G, B and R signals output
from the RGB/SYNC connector.
12P CONNECTOR
Switches the input and output of the
connector (12-pin). Selects the output signal from this
connector when OUT is selected.
Selection Function
IN Functions as the input connector.
OUT Functions as the output connector.
Select the output signal with the SIGNAL setting.
HD/VD: Outputs the HD/VD signal.
C. SYNC: Outputs the composite sync signal.
VBS lock
Appears only when an external reference sync signal (VBS
signal) is input. Adjusts the horizontal phase and SC
(subcarrier) phase to synchronize the camera operation with
the reference signal.
Selection
H.PHASE
SC.PHASE
ROUGH
SC.PHASE
DC IN/VBS FINE
HD/VD lock
Appears only when an external reference sync signal (HD/
VD signal) is input. Adjusts the horizontal phase to
synchronize the camera operation with the reference signal.
Select H.PHASE, then adjust the level within the range from
–20 to +127.
Function
Adjusts the horizontal phase within the range from
–20 to +127.
Roughly adjusts the subcarrier phase by setting to 0° or
180°.
Finely adjusts the subcarrier phase within the range from
–127 to +127.
