Specifications
Image system/optical system
Image device
1/3 type CCD, interline transfer type
Effective picture elements
768 (horizontal) 494 (vertical)
Lens mount C-mount
Video system
Synchronization
Internal/external synchronization (VBS, HD/
VD), switched automatically
Signal format
NTSC standard format (EIA standard)
Scanning
525 lines, 2:1 interlace
Scanning frequency
15.734 kHz (horizontal), 59.94 Hz (vertical)
54
(GB)
Chapter 4 Appendix
Functions/performance
Horizontal resolution
800 TV lines
Sensitivity
2000 lux (F8, 3,200K)
Signal-to-noise ratio
62 dB
Gain control AGC: Automatic Gain Control
STEP: 0–24 dB (in units of 1 dB)
HYPER
White balance
AWB: R. PAINT, B. PAINT
MANUAL: R. GAIN, B. GAIN
ATW: R. PAINT, B. PAINT
3200K
5600K
Electronic shutter speed
Adjustable in the range from 1/100000 to
about 8.0 sec. (adjustable with CCD IRIS)
Linear matrix
ON/OFF switchable
Gamma compensation
ON/OFF switchable
Charge accumulation mode
Switchable between field and frame mode
