‫ﻋﺮﺑﻲ‬
334 |
:‫ﳚﺐ ﺃﻥ ﺗﻄﺒﻖ ﺍﳋﻄﻮﺍﺕ ﺍﻟﺘﺎﻟﻴﺔ ﻗﺒﻞ ﻧﻘﻞ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬
.‫ﺭﻛﺰ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﰲ ﻭﺿﻊ ﺍﻟﻨﻘﻞ‬
337
(
.‫ﺃﺑﻌﺪ ﲨﻴﻊ ﻗﻄﻊ ﺍﻟﺘﻮﺍﺑﻊ ﺍﻟﺘﻲ ﻻ ﻳﻤﻜﻦ ﺗﺜﺒﻴﺘﻬﺎ ﺑﺎﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﺑﺈﺣﻜﺎﻡ‬
.‫ﺿﻊ ﻧﺼﺎﻝ ﺍﳌﻨﺸﺎﺭ ﺍﻟﺘﻲ ﻻ ﻳﺘﻢ ﺍﺳﺘﻌﲈﳍﺎ ﰲ ﻭﻋﺎﺀ ﻣﻐﻠﻖ ﺃﺛﻨﺎﺀ ﺍﻟﻨﻘﻞ ﺇﻥ ﺃﻣﻜﻦ‬
‫ﻧﺤﻮ ﺍﳋﻠﻒ ﲤﺎﻣﺎ ﻭﺍﺿﻐﻂ ﻣﻘﺒﺾ ﺍﻟﻘﻤﻂ‬
15
. ‫ﻟﻒ ﻛﺒﻞ ﺍﻟﺸﺒﻜﺔ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﺣﻮﻝ ﺣﻮﺍﻣﻞ ﺍﻟﻜﺒﻞ‬
29
.‫ﻣﻦ ﺃﺟﻞ ﺍﻟﺮﻓﻊ ﺃﻭ ﺍﻟﻨﻘﻞ‬ ‫ﺃﻭ ﻣﻘﺒﺾ ﺍﳊﻤﻞ‬
13
‫ﺍﺳﺘﺨﺪﻡ ﲡﻬﻴﺰﺍﺕ ﺍﻟﻨﻘﻞ ﺩﺍﺋﲈ ﻋﻨﺪ ﻧﻘﻞ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﻭﻻ ﺗﺴﺘﺨﺪﻡ ﺃﺑﺪﺍ‬
‫ﻳﺘﻢ ﲪﻞ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﻣﻦ ﻗﺒﻞ ﺷﺨﺼﲔ ﺍﺛﻨﲔ ﺩﺍﺋﲈ ﻣﻦ ﺃﺟﻞ ﲡﻨﺐ‬
‫ﺍﺳﺤﺐ ﺍﻟﻘﺎﺑﺲ ﻣﻦ ﻣﻘﺒﺲ ﺍﻟﺸﺒﻜﺔ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﻗﺒﻞ ﺇﺟﺮﺍﺀ ﺃﻱ ﻋﻤﻞ ﻋﻠﯽ‬
‫ﻋﻨﺪ ﺣﺪﻭﺙ ﺃﻱ ﺧﻠﻞ ﺑﺎﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﺑﺎﻟﺮﻏﻢ ﻣﻦ ﺃﳖﺎ ﻗﺪ ﺻﻨﻌﺖ ﺑﻌﻨﺎﻳﺔ ﻓﺎﺋﻘﺔ‬
‫ﻭﺍﺟﺘﺎﺯﺕ ﺍﺧﺘﺒﺎﺭﺍﺕ ﻋﺪﻳﺪﺓ ﺗﻮﺟﺐ ﺇﺻﻼﺣﻬﺎ ﰲ ﻣﺮﻛﺰ ﺧﺪﻣﺔ ﻭﻛﺎﻟﺔ ﻋﺪﺩ ﺑﻮﺵ‬
‫ﻳﺮﺟﯽ ﺫﻛﺮ ﺭﻗﻢ ﺍﻟﺼﻨﻒ ﺑﺎﳌﺮﺍﺗﺐ ﺍﻟﻌﴩ ﺣﺴﺐ ﻻﺋﺤﺔ ﻃﺮﺍﺯ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬
.‫ﺑﺸﻜﻞ ﴐﻭﺭﻱ ﻋﻨﺪ ﺍﻻﺳﺘﺸﺎﺭﺓ ﻭﻋﻨﺪ ﺇﺭﺳﺎﻝ ﻃﻠﺒﻴﺎﺕ ﻗﻄﻊ ﺍﻟﻐﻴﺎﺭ‬
‫ﺣﺎﻓﻆ ﻋﻠﯽ ﻧﻈﺎﻓﺔ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﻭﺷﻘﻮﻕ ﺍﻟﺘﻬﻮﻳﺔ ﻟﻜﻲ ﺗﻌﻤﻞ ﺑﺸﻜﻞ ﺟﻴﺪ‬
‫ﺃﺯﻝ ﺍﻟﻐﺒﺎﺭ ﻭﺍﻟﻨﺸﺎﺭﺓ ﺑﻌﺪ ﻛﻞ ﺧﻄﻮﺓ ﻋﻤﻞ ﻣﻦ ﺧﻼﻝ ﻧﻔﺨﻬﺎ ﺑﺎﳍﻮﺍﺀ ﺍﳌﻀﻐﻮﻁ‬
SAE 10/SAE 20
.‫ﺯ ﻳ ﹼ ﺖ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﻋﻨﺪ ﺍﻟﴬﻭﺭﺓ ﺑﺎﻷﻣﺎﻛﻦ ﺍﳌﺸﺎﺭ ﺇﻟﻴﻬﺎ‬
.‫ﻳﻨﻔﺬ ﻣﺮﻛﺰ ﺧﺪﻣﺔ ﺯﺑﺎﺋﻦ ﻭﻛﺎﻟﺔ ﺑﻮﺵ ﻫﺬﻩ ﺍﻷﻋﲈﻝ ﺑﺸﻜﻞ ﴎﻳﻊ ﻭﻣﻮﺛﻮﻕ‬
‫ﲣﻠﺺ ﻣﻦ ﻣﻮﺍﺩ ﺍﻟﺘﺸﺤﻴﻢ ﻭﺍﻟﺘﻨﻈﻴﻒ ﺑﻄﺮﻳﻘﺔ ﻣﻨﺼﻔﺔ ﺑﺎﻟﺒﻴﺌﺔ. ﺗﻘﻴﺪ ﺑﺎﻷﺣﻜﺎﻡ‬
1 619 929 J53 | (10.5.11)
‫ﲪﻞ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬
–
‫)ﺭﺍﺟﻊ "ﻭﺿﻊ ﺍﻟﻨﻘﻞ"، ﺍﻟﺼﻔﺤﺔ‬
–
–
‫ﺍﺩﻓﻊ ﲤﺪﻳﺪ ﻣﻨﻀﺪﺓ ﺍﻟﻨﴩ‬
14
.‫ﻟﻠﺘﺜﺒﻴﺖ ﻧﺤﻮ ﺍﻷﺳﻔﻞ‬
–
–
‫ﺍﺳﺘﺨﺪﻡ ﺍﳌﻘﺎﺑﺾ ﺍﳌﺨﺪﺩﺓ‬
4

.‫ﲡﻬﻴﺰﺍﺕ ﺍﻟﻮﻗﺎﻳﺔ‬

.‫ﺇﺻﺎﺑﺎﺕ ﺍﻟﻈﻬﺮ‬
‫ﺍﻟﺼﻴﺎﻧﺔ ﻭﺍﳋﺪﻣﺔ‬
‫ﺍﻟﺼﻴﺎﻧﺔ ﻭﺍﻟﺘﻨﻈﻴﻒ‬

.‫ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬
.‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬
‫ﺍﻟﺘﻨﻈﻴﻒ‬
–
.‫ﻭﺁﻣﻦ‬
–
.‫ﺃﻭ ﺑﻮﺍﺳﻄﺔ ﻓﺮﺷﺎﺓ‬
‫ﺗﺸﺤﻴﻢ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬
:‫ﻣﺎﺩﺓ ﺍﻟﺘﺸﺤﻴﻢ‬
‫ﺯﻳﺖ ﺍﳌﺤﺮﻛﺎﺕ‬
–
Z
( ‫)ﺭﺍﺟﻊ ﺍﻟﺼﻮﺭﺓ‬
.‫ﺍﻟﻘﺎﻧﻮﻧﻴﺔ‬
‫ﺑﻮﺍﺳﻄﺔ ﻣﻔﻚ ﺑﺮﺍﻏﻲ ﻣﺘﺼﺎﻟﺒﺔ ﺍﳊﺰ ﻭﻗﻢ ﺑﺘﺴﻮﻳﺔ ﻣﺆﴍ ﺍﻟﺒﻌﺪ‬
( ‫ﺿﺒﻂ ﻣﺴﺘﻮی ﺻﻔﻴﺤﺔ ﺍﻟﺘﻠﻘﻴﻢ )ﺭﺍﺟﻊ ﺍﻟﺼﻮﺭﺓ‬
X
‫ﻣﻊ ﻣﻨﻀﺪﺓ ﺍﻟﻨﴩ ﺃﻭ ﺃﻥ‬ ‫ﳚﺐ ﺃﻥ ﻳﺘﺴﺎﻃﺢ ﺍﳉﺎﻧﺐ ﺍﻷﻣﺎﻣﻲ ﻟﺼﻔﻴﺤﺔ ﺍﻟﺘﻠﻘﻴﻢ‬
24
‫ﻳﺮﻛﺰ ﲢﺘﻬﺎ ﺑﻘﻠﻴﻞ، ﻭﳚﺐ ﺃﻥ ﻳﺘﺴﺎﻃﺢ ﺍﳉﺎﻧﺐ ﺍﳋﻠﻔﻲ ﻣﻊ ﻣﻨﻀﺪﺓ ﺍﻟﻨﴩ ﺃﻭ ﺃﻥ‬
‫ﻟﻀﺒﻂ ﺍﳌﺴﺘﻮی ﺍﻟﺼﺤﻴﺢ‬ ‫ﺍﺳﺘﺨﺪﻡ ﻣﻔﺘﺎﺡ ﺍﻟﺮﺑﻂ ﺍﳌﺴﺪﺱ ﺍﳊﻮﺍﻑ‬
64
.‫ﺑﻌﺪ ﺍﻻﺳﺘﻌﲈﻝ ﺍﳌﺘﻜﺮﺭ‬
‫ﺇﻟﯽ ﺃﻥ ﻳﻌﻮﺩ ﻭﻳﺴﻤﺢ ﺑﺘﺜﺒﻴﺖ ﻣﺼﺪ ﺍﻟﺘﻮﺍﺯﻱ ﻋﻠﯽ‬
(
Y1–Y6
.‫ﺗﻮﻓﺮ ﻟﻚ ﺍﻟﻌﺪﺓ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﺇﻣﻜﺎﻧﻴﺔ ﺗﺜﺒﻴﺖ ﻋﻨﺎﴏ ﻣﻌﻴﻨﺔ ﻣﻦ ﺍﳉﻬﺎﺯ ﺑﺸﻜﻞ ﺁﻣﻦ‬
. ‫ﻋﻦ ﻣﺼﺪ ﺍﻟﺘﻮﺍﺯﻱ‬
10
.‫ﻟ ﻘ ﹼ ﻢ ﲨﻴﻊ ﺃﺟﺰﺍﺀ ﺍﳉﻬﺎﺯ ﺍﻟﺴﺎﺋﺒﺔ ﰲ ﳐﺎﺯﻥ ﺣﻔﻈﻬﺎ ﻋﻠﯽ ﺍﳍﻴﻜﻞ‬
‫ﳐﺰﻥ ﺍﳊﻔﻆ‬
‫ﻭﺍﺣﻜﻢ‬ ‫ﻋﻠﻘﻪ ﰲ ﲡﻮﻳﻒ ﺍﳊﺎﻣﻞ‬
33
‫ﺃﻭ‬ ‫ﺷﺪﻩ ﺑﻮﺍﺳﻄﺔ ﺫﺭﺍﻉ ﺍﻟﺰﻧﻖ‬
8.1
‫ﻟﻮﻟﺐ ﺍﻟﺰﻧﻖ‬
8.2
‫ﺍﺷﺒﻜﻪ ﰲ ﺍﳊﻮﺍﻣﻞ‬
65
‫ﺍﺩﻓﻌﻬﺎ ﺇﻟﯽ ﺩﺍﺧﻞ ﻣﺸﺎﺑﻚ ﺍﻟﻘﺒﺾ‬
66
‫ﺛﺒ ﹼ ﺘﻪ ﰲ ﳐﺰﻥ ﺍﻟﻌﺪﺩ ﺑﻮﺍﺳﻄﺔ ﺻﺎﻣﻮﻟﺔ‬
‫ﺍﻟﺘﺜﺒﻴﺖ‬
67
‫ﻋﻠﻘﻬﺎ ﻓﻮﻕ ﺻﺎﻣﻮﻟﺔ ﺍﻟﺘﺜﺒﻴﺖ‬
67
‫ﻭﺛﺒﺘﻬﺎ ﻣﻦ ﺧﻼﻝ ﺇﺯﺍﺣﺘﻬﺎ‬
‫ﺍﻗﻠﺒﻪ، ﻭﻋﻠﻘﻪ ﰲ ﺳﻜﻚ ﺍﻟﺘﻮﺟﻴﻪ ﻣﻦ‬
‫ﺍﻷﺳﻔﻞ ﻭﺷﺪ ﻣﻘﺒﺾ ﺍﻟﻘﻤﻂ‬
35
‫ﺑﺈﺣﻜﺎﻡ‬
‫ﺍﺩﻓﻌﻪ ﺇﻟﯽ ﺩﺍﺧﻞ ﺍﳊﻮﺍﻣﻞ‬
68
‫ﺍﺩﻓﻌﻪ ﺇﻟﯽ ﺩﺍﺧﻞ ﻣﺸﺎﺑﻚ ﺍﻟﻘﺒﺾ‬
69
‫ﺍﺩﻓﻌﻪ ﺇﻟﯽ ﺩﺍﺧﻞ ﻣﺸﺎﺑﻚ ﺍﻟﻘﺒﺾ‬
،‫)ﺍﳉﺎﻧﺐ ﺍﻟﻘﺼﲑ ﻧﺤﻮ ﺍﻷﻋﻠﯽ‬
30
(‫ﺍﳉﺎﻧﺐ ﺍﻟﻄﻮﻳﻞ ﻧﺤﻮ ﺍﳋﻠﻒ‬
:‫ﺍﻟﻀﺒﻂ‬
–
‫ﺣﻞ ﺍﻟﻠﻮﻟﺐ‬
62
0
.° ‫ﻋﻠﯽ ﻣﺴﺎﺭ ﻋﻼﻣﺔ ﺍﻟـ‬
:‫ﺍﻟﻔﺤﺺ‬
.‫ﻳﺮﻛﺰ ﻓﻮﻗﻬﺎ ﺑﻘﻠﻴﻞ‬
:‫ﺍﻟﻀﺒﻂ‬
–
. ‫ﻓﻚ ﺻﻔﻴﺤﺔ ﺍﻟﺘﻠﻘﻴﻢ‬
24
–
. ‫ﺑﻠﻮﺍﻟﺐ ﺍﻟﻀﺒﻂ ﺍﻷﺭﺑﻌﺔ‬
63
‫ﺿﺒﻂ ﻗﻮﺓ ﺷﺪ ﻣﺼﺪ ﺍﻟﺘﻮﺍﺯﻱ‬
‫ﻗﺪ ﺗﱰﺍﺟﻊ ﻗﻮﺓ ﺷﺪ ﻣﺼﺪ ﺍﻟﺘﻮﺍﺯﻱ‬
10
–
‫ﺗﺎﺑﻊ ﺑﺸﺪ ﻟﻮﻟﺐ ﺍﻟﻀﺒﻂ‬
70
.‫ﻣﻨﻀﺪﺓ ﺍﻟﻨﴩ ﺑﺈﺣﻜﺎﻡ‬
‫ﺍﳋﺰﻥ ﻭﺍﻟﻨﻘﻞ‬
‫ﺣﻔﻆ ﻋﻨﺎﴏ ﺍﳉﻬﺎﺯ )ﺭﺍﺟﻊ ﺍﻟﺼﻮﺭ‬
–
‫ﺣﻞ ﻣﺼﺪ ﺍﻟﺘﻮﺍﺯﻱ ﺍﻹﺿﺎﰲ‬
37
–
(‫)ﺭﺍﺟﻊ ﺍﳉﺪﻭﻝ‬
‫ﻋﻨﴫ ﺍﳉﻬﺎﺯ‬ ‫ﺍﻟﺼﻮﺭﺓ‬
Y1
‫ﻏﻄﺎﺀ ﺍﻟﻮﻗﺎﻳﺔ‬
6.x
Y2
‫ﻃﻘﻢ ﺍﻟﺘﺜﺒﻴﺖ "ﻣﺼﺪ‬
"‫ﺍﻟﺘﻮﺍﺯﻱ ﺍﻹﺿﺎﰲ‬
38
Y2
‫ﻭﺻﻠﺔ ﺷﻔﻂ ﻣﻬﺎﻳﺌﺔ‬
32
Y3
‫ﻣﻔﺘﺎﺡ ﺣﻠﻘﻲ‬
22
Y3
‫ﻋﺼﺎ ﺩﻓﻊ‬
23
Y4
‫ﻣﺼﺪ ﺍﻟﺘﻮﺍﺯﻱ‬
10
Y5
‫ﻣﻔﺘﺎﺡ ﺭﺑﻂ ﻣﺴﺪﺱ‬
‫ﺩﺍﺧﻠﻴﺎ‬
21
‫ﻣﻔﺘﺎﺡ ﺭﺑﻂ ﻣﺴﺪﺱ‬
‫ﺩﺍﺧﻠﻴﺎ‬
64
Y5
‫ﻣﺼﺪ ﺯﺍﻭﻱ‬
3
Y6
‫ﻣﺼﺪ ﺗﻮﺍﺯﻱ ﺇﺿﺎﰲ‬
37
