Anleitung_BT_SM_3100_SPK1:_
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machineʼs moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
6.2 Assembling the saw (Fig. 1-5)
To adjust the turntable (17), loosen the locking
grip (14) by approx. 2 turns, which frees the
turntable (17). To adjust the turntable 2 turns,
which frees the turntable (17).
Turn the turntable (17) and scale pointer (15) to
the desired angular setting on the dial (16) and
lock into place with the locking grip (14). The saw
has locking positions at the following angles: -
45°, -30°, -22.5°, -15°, 0°, 15°, 22.5°, 30° and
45°, into which the turntable snaps into place
To release the saw from its position at the bottom,
pull the locking pin (25) out of the motor mounting
while pressing down lightly on the machine head
(4). Turn the locking pin (25) through 90° before
you release it so that the saw remains released.
Swing the machine head (4) up until the release
lever (3) latches into place.
The clamping device (8) can be fitted on either the
left or right of the fixed saw bench (18).
Undo the locking screws for the workpiece
support (30).
Mount the workpiece support (10) on the fixed
saw table (18) and tighten the appropriate locking
screw (26) (Figure 4).
Mount the second workpiece support (10) on the
opposite side of the saw and secure with the
appropriate locking screw (30).
Mount the additional stability bar (9) on the back
side of the saw and fix into place (Fig. 5) with the
appropriate locking screw (37)
When the locking screw (21) is loosened, you can
tilt the machine head (4) to the left by up to 45°.
To ensure the saw is securely standing, adjust
the supporting foot (13) by turning until the saw
is horizontal and stable.
6.3 Final adjustment of the stop for crosscut 90°
(Fig. 7-8)
Fasten the turntable (17) in 0° position.
Undo the securing screw (21) and tilt the machine
head (4) as far to the right as possible using the
handle (1).
Place the 90° angular stop (a) between the saw
blade (7) and the turntable (17).
Adjust the adjustment screw (29) until the angle
15.06.2010
11:53 Uhr
Seite 17
between the Saw blade (7) and the turntable(17)
is 90°
Finally check the position of the pointer (20) on
the scale (19). If necessary undo the pointer (20)
with a Philips screwdriver, set it to the 0° position
on the scale (19) and tighten the retaining screw
again.
An angular stop is not supplied.
6.4 Final adjustment of the stop for meter cut 45°
(Fig. 1, 6, 7, 9)
Fasten the turntable (17) in 0° position.
Undo the securing screw (21) and tilt the machine
head (4) to the right to an angle of 45° using the
handle (1).
Place the 45° stop angle (b) between the blade
(7) and the turntable (17).
Adjust the adjustment screw (30) until the angle
between the saw blade (7) and the turntable (17)
is 45°.
An angular stop is not supplied.

7. Operation

7.1 Crosscut 90° and turntable 0° (Fig. 1 – 3, 10)
For cutting widths up to 100 mm it is possible to fix
the saw's drag function in its rear position with the
fixing screw for drag guide (24). If the cutting width
exceeds 100 mm you must ensure that the fixing
screw for the drag guide (24) is undone and that the
machine head (4) can be moved.
Move the machine head (4) to its upper position.
Use the handle (1) to push back the machine
head (4) and fix it in this position if required
(dependent on the cutting width).
Place the piece of wood to be cut at the stop rail
(11) and on the turntable (17).
Lock the material with the clamping device (8) on
the fixed saw bench (18) to prevent the material
from moving during the cutting operation.
Push down the release lever (3) to release the
machine head (4).
Press the ON/OFF switch (2) to start the motor.
If the drag guide (23) is fixed: Move the machine
head (4) downwards evenly and with gentle
pressure using the handle (1) until the saw blade
(7) has cut through the workpiece.
If the drag guide (23) is not fixed:
Pull the machine head (4) as far as possible
forwards and then lower it evenly and with gently
pressure using the handle (1). Now push the
machine head (4) slowly and evenly right to the
rear until the saw blade (7) has cut right through
the workpiece.
When the cutting operation is completed, move
GB
17
