UK | 1 Scope of delivery

1 Scope of delivery

Scope of delivery depends on the
i
system configuration.
LD 30 BO / LD 30 BK ventilation unit
● Internal cover, complete: Housing,
2 G3 air filter and front cover.
● Slide-in module (including 2 fan units and
2 ceramic heat exchangers)
● 1 extension duct 200 mm long, 1 centring
ring, 2 sealing bands.
● 1 internal housing drilling template
● These mounting instructions for final moun-
ting kit.
2 Specialist installer qualification
Shell measures may only be undertaken by a
trained specialist. Only a trained electrician
is permitted to undertake final mounting and
work on the electrics. You are considered a
trained electrician if your specialist training
and experience
● means that you are familiar with the relevant
standards and guidelines
● enables you to correctly and safely under-
take the electrical connections in accord-
ance with the wiring diagram provided and
● enables you to recognise and avoid risks
and hazards associated with electricity.
After successful installation and commis-
sioning, instruct users in the ventilation
unit and operating units.

3 Intended use

LD 30 ventilation units with heat recovery are
used for air extraction and ventilation of apart-
ments, offices and similar rooms. They are
suitable for new builds as well as renovation
work. The housing unit's ventilation system
should be configured in accordance with DIN
1946-6.
LD 30 are balanced ventilation units, which
are the ideal choice for use in exhaust air rooms
(bathroom, WC or kitchen with windows)
24
and aerate and ventilate the rooms at the
same time. Exhaust air mode is started
automatically depending on the setting or can
be started manually at the touch of a button
(when the button/switch is connected).
LD 30 are stand-alone units or can be used
in groups with other LD 30/LD 45 units. LD 30
can also be used in damp rooms, protective
zone 1. Combinations of LD 30 BK units with
exhaust air units are not possible.
LD 30 are installed in outside walls (wall
thickness 320-790 mm, installation position
with slight incline towards the outside wall)
and are connected to a permanently wired
electrical installation.
The LD 30 models "BO" for object and "BK"
for comfort are available. They are operated
using the
LDS 45 K or LDS 45 O room air control.
LDS 45 K: 3 operating modes (heat recovery,
cross-ventilation, automatic mode),
5 ventilation levels, time-limited intermittent
ventilation,
time-limited switch-off, safety switch-off, Mod-
Bus, configuration with PC.
LD 45 EO-ER radio module can be added
to integrate radio sensors.
LDS 45 O: 3 operating modes (heat recovery,
cross-ventilation, automatic mode), 5
ventilation levels, configuration using service
menu.
LD 30 BK units cannot be operated in
i
combination with an LDS 45 O.
Combinations of LD 30 BK with ex-
haust air units are not possible.
The fan/heat exchanger unit is designed as a
duct mounting and can be removed for repair
and cleaning purposes.
LD 30 ventilation units are only intended for
domestic use and similar purposes. No other
or additional use is intended.
