ELECTRICAL
ELECTRICAL CONNECTION
This product has a precision-built electric motor. It should
be connected to a power supply that is 220-240 volts,
50 Hz, AC only (normal household current). Do not
operate this product on direct current (DC). A substantial
voltage drop will cause a loss of power and the motor will
overheat. If the product does not operate when plugged
into an outlet, double-check the power supply.
EXTENSION CORDS
The cross-section of any extension cables used must be
proportional to their length, i.e. the longer the extension
cable, the greater the cross-section; cables with a
protection level of "IPX5" must be used.
Use the chart to determine the minimum wire size
required in an extension cord.
Extension cable
Voltage
up to 25m
Motor
220-240v
3 x 1.5mm²
Rated voltage
Rated Pressure
Permissible Pressure
Power Rating
Maximum Water Flow
Maximum Water Inlet pressure
LWA(sound power level)
LpA(sound pressure level)
Protection Degree
Vibration r.m.s. acceleration
DESCRIPTION
(Fig.1)
1. Gun with safety lock
2. Lance with adjustable spraying nozzle
3. Detergent Tank
4. Water outlet (OUTLET)
5. On/Off Switch
6. Rating Plate
7. Water inlet with filter (INLET)
8. Operator's manual
PT
NL
SV
DA
NO
English(original instructions)
Extension cable
up to 50m
section
section
3 x 2.5mm²
PRODUCT SPECIFICATIONS
V~/Hz
Bar (Mpa)
Bar (Mpa)
W
L/min
Bar (Mpa)
dB(A)
dB(A)
IEC 60529
2
m/s
FI
HU CS RU
RO PL
Position the cleaner as NEAR as possible to the
■
water supply.
The cleaner must be used standing on a secure,
■
stable surface, positioned as shown. (Fig. 2)
WARNING:
Keep the extension cord clear of the working
area. Position the cord so that it will not get
caught on lumber, tools, or other obstructions
while you are working with a power tool. Failure to
do so can result in serious personal injury.
WARNING:
Check extension cords before each use. If
damaged replace immediately. Never use the
product with a damaged cord since touching
the damaged area could cause electrical shock
resulting in serious injury.
SAVE THESE INSTRUCTIONS
RPW100S
220-240/50
70(7)
105(10.5)
1400
6
7(0.7)
96
84
IPX5
1.2
9. Nozzle cleaning tool
10. High pressure hose
11. Electrical cable and power plug
INTENDED USE
The cleaner is intended only for the cleaning of
■
vehicles, machines, boats, buildings, etc., by the
removal of stubborn dirt using clean water and
chemical detergents.
For domestic use only, not for professional use, and
■
only for operation at temperatures above 0° C .
11
SL
HR ET
LT
LV
SK BG
RPW120S
220-240/50
90(9)
130(13)
1600
6
7(0.7)
96
84
IPX5
1.2
