Setting up the patient

Place the KINETEC Spectra machine in a position that will be comfortable for the patient.
- Measure in cm or inches the length of the patient's femur (L); adjust the thigh support to this measurement using knobs (5)
- To install the patient on the KINETEC Spectra machine.
- Push the foot plate (3) up to the patient and tighten the knobs (6).
- Adjust the plantar flexion (40°) or the dorsal flexion (30°) of the foot, with the knobs (7).
- Adjust the internal (30°) or external (30°) flexion of the foot, with the knob (27).
IMPORTANT
Adjust the axis of the patient's hip (28) with the axis rotation (29) of the KINETEC Spectra machine,
and the axis of the patient's knee (30) with the axis rotation (31) of the KINETEC Spectra machine.
31
6
3
30
L
7
29
28
27
5
