Heating circuit auto. 1 and Heating circuit auto. 2
[→ Main menu → Time program → HC auto 1 /HC auto 2]
The time programs for the HC can be parametrised in these menus.
Three switching cycles can be set per day, to which the [Room tem-
perature target 1/2/3] parameters are assigned. Outside the switch-
ing cycles, it is controlled to the [Room temperature reduced] set-
point. The entry can be made separately for each individual weekday
or in week segments.
Time period
Temperature setting
Monday - Friday
Saturday, Sunday
Monday - Friday
Saturday, Sunday
Temperature setting
Monday - Sunday
Monday - Friday
Saturday, Sunday
Monday - Friday
Saturday, Sunday
Tab. 4-3 Factory setting of the permanent time program
4.3.3

Time program reset

[→ Main menu → Time program → TP reset]
This menu can be used to reset the time programs to factory set-
tings. To do this, select the respective time programs and then con-
firm the selection with the Confirm button on the second menu page.
4.4

Settings

[→ Main menu → Settings]
The basic settings of the controller and the system are made in this
menu. This includes the integration of optional and external compon-
ents. Depending on the access authorisation (user or expert), differ-
ent parameters are available.
Daikin RoCon+ HP
Daikin Controller RoCon+ HP
008.1444299_01 – 09/2018 – EN
Switching cycle 1
On Off
[Room temperature setpoint 1]:
20 °C
"Heating circuit automatic 1"
06:00 22:00
07:00 23:00
"Heating circuit automatic 2"
06:00 08:00
07:00 23:00
Domestic hot water preparation
[Hot water temp. setpoint 1]: 60 °C
"Hot water automatic 1"
05:00 21:00
"Hot water automatic 2"
05:00 21:00
06:00 22:00
"Circulation program"
05:00 21:00
06:00 22:00
Hot water auto. 1 and Hot water auto. 2
[→ Main menu → Time program → DHW auto 1 /DHW auto 2]
The time programs for the domestic hot water preparation can be
parametrised in these menus. Three switching cycles can be set per
day, to which the [Hot water temperature, target 1/2/3] parameters
are assigned.
Circulation program
[→ Main menu → Time program → Circulation]
A time program for an optionally connected circulation pump can be
parametrised in this menu. 3 switching cycles per day can be set.
INFORMATION
Use of circulation lines not permitted in France!
Factory settings
The permanent time programs are preset according to
Switching cycle 2
On Off
Room heating
[Room temperature setpoint 2]:
20 °C
[Room temperature reduced]: 10 °C
- - : - - - - : - -
- - : - - - - : - -
16:00 22:00
- - : - - - - : - -
[Hot water temp. setpoint 2]: 60 °C
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
4.4.1

Display settings

[→ Main menu → Settings → Display]
This menu can be used to set the following parameters: Language,
date, time, LCD brightness and LCD illumination duration.
Further explanations and possible settings for this menu can be
found in Chap. 7.5.
INFORMATION
Increasing the brightness of the LCD display beyond the
factory-set value will reduce the life of the display.
4 Function
Tab. 4-3.
Switching cycle 3
On Off
[Room temperature setpoint 3]:
20 °C
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
[Hot water temp. setpoint 3]: 60 °C
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
- - : - - - - : - -
