8. Control elements

• Remove the blade (26) from the blade pulleys (7, 8) and take out through the slot in the
GB
table (15).
• Fit the new blade (26), aligned centrally on the blade pulleys (7, 8).
The teeth of the blade (26) must point downwards in the direction of the table.
• Tension the blade (26) (see 7.2)
• Close the side cover (12) again.
• Mount the web panel (4) again.

7.9. Changing the rubber tires on the blade pulleys (Figure 15)

After a certain time the rubber tires (3) on the blade pulleys (7/8) will get worn by the sharp teeth
of the blades and must be replaced.
• Open the side cover (12).
• Remove the blade (26) (see 7.7).
• Lift the edge of the tire (3) with a small screwdriver (f) and remove from the blade pulley (8).
• Repeat for the lower blade pulley (7).
• Fit the new tire (3), replace the blade (26) and close the side cover (12).

7.10. Changing the table insert (Figure 16)

To prevent increased likelihood of injury the table insert (17) should be changed whenever it is worn
or damaged.
• Detach the table (15) (see 7.1).
• Lift out the worn table insert (17).
• Fit the replacement table insert by following the above in reverse.

7.11. Extractor sockets

The bandsaw is equipped with extractor sockets (6) for extracting sawdust and chips.
8. Control elements

8.1. On/Off switch (Figure 17)

• To turn the machine on, press the green button „1" (g).
• To turn the machine off again, press the red button „0" (h).
• Your bandsaw has a switch with undervoltage release. After a power failure you must reactivate
the switch.

8.2. Parallel stop (Figure 18)

• Push the clip (21) on the parallel stop (24) upwards.
• Move the parallel stop (24) along the table (15), from either the right or left of the blade (26),
and position as required.
• Push the clip (21) down to fix the parallel stop (24). If the clip (21) does not give enough hold,
turn it clockwise several times until the parallel stop is securely fixed.
• You must always ensure that the parallel stop (24) is positioned parallel to the blade (26).

8.3. Angular cuts (Figure 19)

To enable you to perform angular cuts parallel to the blade (26), the table (15) can be tilted forwards
between 0° – 45°.
• Undo the fixing handles (18).
