1. Machine layout (Figures 1/2)

1. ON/OFF switch
2. Power cord
3. Rubber tires
4. Web panel
5. Machine foot
6. Extractor socket
7. Lower blade pulley
8. Upper blade pulley
9. Tightening screw
10. Blade guard
11. Upper blade guide
12. Side cover
13. Hood closure
14. Retaining screw for upper blade pulley
15. Saw table
16. Dial scale for tilt angle
17. Plastic table insert
18. Fixing handles for saw table
19. Setting handle for blade guide
20. Fixing handle for blade guide
21. Clip for parallel stop
22. Setting screw for upper blade pulley
23. Motor
24. Parallel stop
25. Machine frame
26. Blade

Items supplied

• Bandsaw
• Saw table
• Push stick
• Parallel stop

Proper use

The bandsaw is designed to perform longitudinal and cross cuts on timber or wood-type materials.
To cut round materials you must use suitable holding devices.
The machine is to be used only for its prescribed purpose.
Any use beyond that mentioned is considered to be a case of misuse. The user/operator and not
the manufacturer shall be liable for any damage or injury resulting from such cases of misuse.
