KitchenAid KUDS01DL Guide D'utilisation Et D'entretien page 11

To remove small insert
Front view from inside rack
1. Pull out toward the back of rack and lift up to release.
2. Lift insert out of rack.
NOTE: It will be easier to install the inserts if you remove the
silverware basket from the rack.
To install large insert
1. Place the large insert end legs under the 2nd from the right
wire as shown below.
2. Make sure that the three hooks on the back of the insert are
placed over the back wire in the bottom of the rack.
3. Push down on insert until handle fits against outer rack edge.
4. When center tab under handle locks in under the middle side
rack wire, the insert is in place. (See illustration.)
To install medium insert
1. Place the medium insert end legs under the 2nd from the
right wire as shown below.
IMPORTANT: Make sure that the curved wires, on the bottom
of the insert, fit over a wire in the bottom of the rack as
shown.
2. Push down on insert until handle fits against outer rack edge.
3. When center tab under handle locks in under the middle side
rack wire, the insert is in place. (See illustration.)
To install small insert
Front view from inside rack
1. Place small insert in front of rack so that the feet on the back
of the insert hook under the 2nd wire from the front, and the
curved front edge of the insert is aligned with the center wire
on the front side of the rack. (See illustration.)
2. Push down on insert until handle fits against outer rack edge.
Front view from inside rack
3. When center tab under handle locks in under the middle side
rack wire, the insert is in place. (See illustration.)
SURE-HOLD™ mesh sack
This sack hangs on the front of the bottom rack. Use it to hold
small items that could otherwise "fly" around inside the
dishwasher during a cycle.
11
