1
2
3
4
5
6
7
8
9
10
11
12
1. Upper spray
2. 2-Position top rack adjuster [two]
3. FLEXI-FOLD DOWN™ flexible tines
4. Removable top rack
5. SATINGLIDE ® upper rack track
6. Model and serial number label
7. Water inlet opening [in tub wall]
8. Removable rack inserts [three]
Control Panel

PARTS AND FEATURES

9. 4-way HYDRO SWEEP™
spray arm
10. Bottom rack
11. Detergent dispenser
12. Vent
13. SURE-HOLD™ utility shelf [two]
14. Top rack
15. FLEXI-SPLIT™ divided tines
16. SURE-HOLD™ light item clips
13
14
15
16
17
18
19
20
21
22
23
24
17. Middle spray arm
18. Silverware basket
19. CULINARY CADDY
20. Overfill protection float
21. Heating element
22. SURE-HOLD™ mesh sack
23. Rinse aid dispenser
24. Control panel
Front Control Panel
® utensil basket
5
