To reduce the risk of fire and burn
injury, use only spark plugs
authorized by STIHL. Always press
spark plug boot (2) snugly onto
terminal (1) of the proper size.
(Note: If terminal has detachable
SAE adapter nut, it must be
attached.) A loose connection
between spark plug boot and
ignition wire connector in the boot
may create arcing that could ignite
combustible fumes and cause a fire.
FS 100 RX
Lubricating the
Gearbox
2
: Check grease level regularly –
about every 25 hours of operation.
1
: Unscrew the filler plug (1).
: If no grease can be seen on the
inside of the filler plug, screw the
tube (2) of STIHL gear lubricant for
brushcutters – see "Special
Accessories" – into the filler hole.
: Squeeze up to 5 g grease into the
gear housing.
Do not completely fill the gear
housing with grease.
: Refit the filler plug and tighten it
down firmly.
1
2
Replacing Starter Rope
and Rewind Spring
1
2
1
Replacing the starter rope
: Move slide control in direction of
c – arrow to $.
: Take out the screws (1).
: Lift the starter cover (2) off the
housing.
English
1
27
