Anleitung HGG 110-171-300_SPK7:_
press the ignition button repeatedly until the
burner ignites (only if the ventilator is rotating).
5. To switch off the heater, always first close the
gas cylinder valve and only then turn off the
ventilator motor and pull the plug out of the
socket outlet.
4. Fuel
HGG 110, HGG 110 Niro, HGG 171 Niro:
Commercially available propane (DIN 51622)
Commercially available butane (DIN 51622)
Pressure reducer 300 mbar
HGG 300 Niro:
Commercially available propane (DIN 51622)
Pressure reducer 1,5 bar
The appliance can be operated in conjunction with
any 5 kg or 11 kg gas cylinder or an even bigger
container. Be sure to use only the following
equipment when connecting the unit to a gas
cylinder: For model HGG 110 Niro/HGG 171 NIRO
/HGG 110 a pressure reducer with an output
pressure of 300 mbar (HGG 300 Niro: 1,5 bar) with
DIN 4811 Part 1, together with a liquefied gas pipe in
compliance with DK 6 according to DIN 4815 Part 2.
5. Ventilation
Caution:
The heater must only be used in well ventilated
areas (heater is not intended for use in enclosed
spaces). The continuous presence of persons in
these rooms is forbidden. If more than one heater is
used in one room, be sure to provide for
correspondingly more fresh air circulation.
6. Maintenance
Before carrying out any maintenance or repair
work, always pull the plug out of the socket outlet
and close the gas cylinder valve.
Remove the pressure regulator with gas hose and
check the gasket for damage. Please contact ISC
GmbH in case of damage.
Never store the liquid gas cylinder inside the
house, under ground or in non-ventilated areas!
The valves on the liquid gas cylinder must have
valve safety caps and locking nuts.
03.04.2009
10:52 Uhr
Seite 11
Gas bottles must be stored upright, even if they
are empty.
The hot air generator can be cleaned with all
standard, non-abrasive and non-flammable liquid
cleaning agents. The equipment must be switched
off and sufficiently cool before cleaning.
Important! Do not clean the equipment with
pressurized water (spraying with a water hose,
steam jet or a high-pressure cleaner).
Repairs and maintenance work on the hot air
generator may only be carried out by authorized
gas fitters.
Only original spare parts should be used for
repairs.
Maintenance: Check the hose lines (gas hose) at
least once per month and every time you change
the liquid gas cylinder. If the hose lines show any
signs of becoming brittle or other damage, you
must replace them with new hoses of the same
length and quality. The equipment, hose lines and
pressure controller should be subjected to a
maintenance inspection by a specialized dealer
every 2 years. Any defective parts must be
replaced during this process.
We recommend that the pressure regulator be
replaced after five years, as rubber gaskets and
diaphragms can become porous.
Keep the equipment free of dust as well as free
from any type of deposits.
Air inlet and outlet grilles must be cleaned at
regular intervals.
Check and adjust the position of the ignition
electrode as shown in Fig. 6.
After completing any maintenance and repair work
you must carry out a function check of the
complete equipment, checking all gas supply
connections for leaks (e.g. with a leakage
detection spray or soap suds) and performing an
electrical safety test in accordance with VDE
0701.
7. Terminal diagram (Pic 7)
Q1 On/Off switch
F1 Safety thermostat
M1 Fan motor
Y1 Thermoelectric ignition fuse
Y2 Safety solenoid valve
B1 Thermoelement
B2 Piezo ignition
B3 Ignition electrode
B4 Burner
11
