CAUTIONS AND WARNINGS

To prevent injury and damage to your scale, please follow these instructions very carefully.
 Do not transport the scale while the platform is loaded. Unplug the adapter and store both the adapter and
cord before moving the scale. Be sure the scale is tilted enough to assure it is rolling properly on its wheels
when it is moved for cleaning or transported from one area to another.
 For accurate weighing the scale must be placed on a flat, stable surface.
 For accurate weighing, verify proper operation according to the procedure described in this manual before
each use. Do not exceed recommended weight limit of 1,000lb/454kg for this scale.
 Do not use in the presence of flammable materials.
 Operating at other voltages and frequencies than specified could damage the equipment.
 If the "LOW BAT" indicator activates, for accurate weighing, replace the batteries or connect the scale to a
power source, using the power adapter, as soon as possible, depending on use—see Connectivity section.

SPECIFICATIONS

GENERAL
®
The ProPlus 4650/4700 Wheelchair Platform Digital Scale for Patients uses highly sophisticated
microprocessor technology. Each precision scale is designed to provide accurate, reliable and
repeatable weight measurements and features that make the weighing process simple, fast and
convenient.
These scales are set up to use motion-sensing weighing technology, to determine the actual weight of
a moving patient. The scales may be changed to measure live weight (see the ProPlus
Module User Manual for instructions on how to change the scale settings).
Weight is displayed in pounds. The scale features a remote display which may be held by the
operator or placed on a table, desk, wall or other flat surface for privacy and convenience in use.
The 4650/4700 has 2 wheels built in for easy mobility. The scale can be operated using a power
adapter (included) or by 6-D cell batteries (not included), depending on use—see Connectivity
section, below.
4650/4700 SPECIFICATIONS
Capacity and
Resolution
Power Requirements 120V-240V AC, 50-60Hz - 9V DC adapter, ADAPTER MODEL ADPT31
Environmental
Physical Dimensions
4650
0044
4650/4700,: Max 1,000 lb / 0.2lb, 454 kg / 0.1 kg
(INCLUDED) or 6 D-cell batteries (not included)
Operating temperatures: 50°F to 95°F (10°C to 35°C)
Storage temperatures 32°F to 122°F (0°C to 50°C)
Maximum Humidity: 85% RH
Platform Size
35 ¾ (w) 32 ¼ (d)
43 (w) x 42 (d)
Ramp Size
10" x 32-1/4"
12-3/4 x 42
®
Display
