HID312 and HID525 50 Hz
Installation and User's Manual

Air filter

The air filter on the left side of the cabinet will capture
significant dust and lint during operation. As the dirt
builds up it begins to restrict air flow and causes the
refrigeration system to work longer to make ice. Clean
the air filter regularly.
To remove, pull it forward from the louvers. Do not
leave it out for extended periods of time.
Remove Top Panel
To clean, wash it at a utility sink. Return it to the unit
when clean.
Condenser.
The condenser fins may need cleaning too. Remove
the left side air grill and brush any lint and dirt off the
surface of the condenser. Vacuum any remaining
dirt. Do not damage the fins of the condenser during
cleaning.
Remove Bin Cover and Ice Delivery Chute
April 2015
Page 13
