4 Inflating items

4.1 Attach accessories for inflation

4 Inflating items
11
9
9
12
9
10
13
If you want to inflate items, prepare your
hand-held vacuum cleaner as follows:
1. First empty and clean the dust container,
Chapter 5.2,
container" and Chapter 5.3, "Cleaning
the dust container".
2. Then clean the permanent filter
5.4, "Cleaning the permanent filter" as well
as the Chapter 5.5, "Cleaning the
exhaust filter".
3. If you have not done so already, open the
exhaust filter cover (Fig. 11).
4. Put the grey inflater hose (Fig. 12/9) into
the rear intake opening of the hand-held
vacuum cleaner (Fig. 12). You will feel
and hear the hose snap into place.
5. Select one of the three inflater nozzles
(Fig. 13/10), depending on the size of the
valve of the object to be inflated.
6. Attach the selected
(Fig. 13/10) to the end of the grey inflater
hose (Fig. 13/9) as shown.
7. Lock the inflater nozzle (Fig. 13/10) by
turning it in the direction of the arrow as
shown (Fig. 13/arrow). You will feel and
hear the nozzle snap into place.
ATTENTION:
Your hand-held vacuum cleaner is not suit-
able for inflating bike tyres.
"Emptying the dust
Chapter
inflater nozzle
