TELEPHONE MUTE
If your car telephone provides a mute signal,it can be used to automatically interrupt the set's
audio output.
• Connect the telephone mute wire to pin A1. Use the small contact supplied (also
availablefrom your dealer). Refer to 'INITIAL SETTINGS', option 'PHONE'
In certainVW and Opel/Vauxhall c ars,the PinA 1 is usedas a speed-dependent v olumecontrol (GALA).
Ask your authorizedVW or Opel/Vauxhall d ealerto modifr this connectionif you want to usethe
telephonemute feature.
CONNECTOR B for loudspeakers
- Only useloudspeakerswhich havean impedanceof 4 ohms.
- Do not connectany of the loudspeakerleadsto earth!
- Do notconnect a booster/amplfier directly to the loudspeaker outputs!
- Do not connectloudspeakers via an external fader!
• Blue lead Bl: Connect to Rear Right speaker (+).
• Blue/black lead B2: Connect to Rear Right speaker (—).
• Grey lead B3: Connect to Front Right speaker (+).
• Grey/black lead B4: Connect to Front Right speaker (—).
• Green lead B5: Connect to Front Left speaker (+).
• Green/black lead B6: Connect to Front Left speaker (—).
• White lead B7: Connect to Rear Left speaker (+).
• White/black lead B8: Connect to Rear Left speaker (—).
METAL SLEEVE
• Insert metal sleeve into the opening (182 x 53 mm) in the car dashboard
or console (fig. 4). See separate installation card. For optimal performance
of the CD player,the metal sleaveshould be mounted horizontally
(between -100 and +450). Consult your dealer for other mounting angles.
• Fix metal sleeve into place by pressing the metal tags outwards using a screwdriver (fig. 5).
CONNECTING RADIO (fig. 6)
Beforeconnecting the connector o f the car to the car radio,checkif the connector f itted in the car has
two wiresin position A2 andA3. If it does,usefor connecting the car radiothe adaptorEA 6261 for
Audi,Opel, V auxhall, VW and Seatcarsand adaptorEA 6262 for carsof othermakes.
• Insert aerial plug E into aerial socket (adaptors for other aerial standards are available
from your dealer). Good reception is only possible with a good aerial.
• Insert power supply plug A into socket A'.
• Insert loudspeaker
MOUNTING RADIO
• Slide the radio into the metal
the openings of the sleeve (fig. 7).
• Reconnect the negative car battery terminal
REMOVING RADIO (fig. 9)
You can unlock the radio using the two IJ-brackets supplied.
• Insert both U-brackets
• Pull the radio out
4 x
plug B into socket B'.
sleeve until the springs at either side of the radio snap into
into the holes on the front
of the metal sleeve.
(fig. 3)
(fig. 8). Installation is now complete.
of the set until they lock.
3
+450
-100
