Translation of the Original Instruction Manual
Fig. 1 – 5
1 Guide hose
2 Guard
3 Switch
4 Carrying and pressure loading
handle
5 Drain cleaning cable
6 Drain cleaning tool
7 T-bar connector
Contents
Safety instructions
General Power Tool Safety Warnings
Safety instructions for electric pipe cleaning machines
1. Technical Data
1.1. Scope of Supply
1.2. Article numbers
1.3. Working range
1.4. Working speed
1.5. Electrical data
1.6. Dimensions (L × W × H)
1.7. Weights
1.8. Noise information
1.9. Vibrations
2. Start-up
2.1. Electrical connection
2.2. Handling and selection of the pipe and drain cleaning cable
2.3. Selection of suitable pipe and drain cleaning tool
3. Operation
3.1. Investigation/removal of the obstruction
3.2. Recovering the pipe and drain cleaning cable
3.3. Cleaning the pipe
3.4. Adapter drum with 8 mm pipe and drain cleaning cable (accessory)
3.5. Taking out of service and transport
4. Maintenance
4.1. Maintenance
4.2. Inspection / maintenance
5. Faults
6. Disposal
7. Manufacturer's Warranty
8. Spare parts lists
General Power Tool Safety Warnings
WARNING
Read all the safety notes, instructions, illustrations and technical data which
come with this power tool. Failure to heed the following instructions can lead to
electric shock, fire and/or severe injuries.
Keep all safety notes and instructions for the future.
The term „power tool" used in the safety notes refers to mains operated power tools
(with power cable).
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the pres-
ence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmod-
ified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not misuse the connecting cable to carry or hang up the power tool or
to pull the plug out of the socket. Keep the connecting cable away from
heat, oil, sharp edges or moving tool parts. Damaged or knotted cables
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
8
8 T-groove connector
9 Cable joint separator
10 Adapter drum (accessory)
11 Fault current circuit breaker PRCD
12 RESET button
13 TEST button
14 PRCD control lamp
15 Mains lead
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) Do not take your safety for granted and ignore the safety rules for power
tools even if you are very familiar with the power tool after frequent use.
Careless handling can lead to severe injury within split seconds.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before making any adjustments,
changing accessories, or storing power tools. Such preventive safety meas-
ures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool's
operation. If damaged, have the power tool repaired by qualified technical
personnel or an authorised REMS service shop before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to
be performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.
h) Keep handles and gripping surfaces dry, clean and free from oil and grease.
Slippery handles and gripping surfaces prevent safe handling and control of the
power tool in unforeseeable situations.
5) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
Safety instructions for electric pipe cleaning machines
WARNING
Read all the safety notes, instructions, illustrations and technical data which
come with this power tool. Failure to heed the following instructions can lead to
electric shock, fire and/or severe injuries.
Keep all safety notes and instructions for the future.
● Never use the electric pipe cleaning machine without the delivered fault
current circuit breaker PRCD. The use of a fault current circuit breaker reduces
the risk of electric shock.
● Only connect the electric pipe and drain cleaning machine to an outlet with
protected earth. There is a danger of electric shock.
● Wear rubber-soled shoes, e.g. Wellington boots, when working with the
electric pipe and drain cleaning machine on a wet floor. These shoes have
an insulating effect and protect against possible electric shock.
● Keep water away from electrical parts of the electric pipe and drain cleaning
machine and from persons in the working area. There is a danger of electric
shock.
● You could encounter concealed power cables when cleaning pipes. The
pipe and drain cleaning cable may also emerge from damaged pipes and hit
concealed or buried power cables. There is a danger of electric shock.
● Only use the riveted guide gloves (Art. No. 172611 and/or 172612) to guide
the revolving cable. There is a danger of injury when using unsuitable gloves
made of, e.g., rubber, leather or similar material and when using a loose cloth
for example.
● Do not operate the electric pipe and drain cleaning machine without the
guard (2) and the guide hose fixed to it (1). There is a danger of injury from
the end of the pipe and drain cleaning cable (5) protruding from the machine
suddenly twisting when the pipe and drain cleaning tool comes up against some
form of resistance and seizes.
● Only use approved and appropriate marked extension leads with a sufficient
