PART NAMES
INDOOR UNIT
AY-XPC15TU
AY-XPC18TU
AY-XP24TU
4
20
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUX Button
5 Receiver Window
6 Vertical Airfl ow Louver
7 Horizontal Airfl ow Louver
8 Outlet (Air)
OM_AY-XPC5PU(A760)_EN-FR-ES.indb EN-5
1
2
3
4
5
6
7
8
9
10
11
12
4
13
9 PLASMACLUSTER Lamp (blue
10 OPERATION Lamp (green
11 TIMER Lamp (orange
12 -4°F/-20°C AUTO OFF Lamp (red
13 FULL POWER Lamp
(green )
