Frigelux RC425XES Manuel D'utilisation page 33

Using a screwdriver, dismantle from the middle hinge, lift the
freezer door upwards to disengage it from the lower hinge.
Put the door to one side and lay it down gently on a padded
3
surface.
Take out the hinge pin out, rotate the hinge 180 degrees,
4
reverse and reinstall it to the opposite side, Swap over the
position of the lower hinge and the adjustable leg to the other
side of the cabinet.
Remove the hinge pin that is in the bottom of the fridge and
5 freezer door. At the other side of fridge and freezer door,
insert the replacement hinge pin that is supplied with the
appliance inside the parts bag.
Place the freezer door on the lower hinge, making sure that
the hinge pin is inserted in the hole at the bottom of the
freezer door, put the middle hinge back on the cabinet,
6
making sure that it is on the opposite side from it original
position.
Place the fridge door on the middle hinge, making sure that
the hinge pin is inserted in the hole at the bottom of the fridge
7
door. Place the top hinge on the fridge door, fixing the screw
and cover.
Take out the cable from the left hole of the door. Take the
left hinge from the parts bag and install it to the left side,
8
tighten all the screws.
Connect the cable to the cabinet.
Take out the left hinge cover from the parts bag. Install lamp
switch on left hinge cover.
Install the left hinge cover on the left hinge and fix it with
screws.
9 Put cable inside hole of door and cover it.
Install cover on the right of cabinet with screws.
33
