Ensure that the choice of blade and the selected
q
speed are suitable for the material to be cut.
Do not begin cleaning the blade until it has come
q
to a complete standstill.
For straight cuts of small workpieces against the
q
longitudinal limit stop the push stick has to be used.
The bandsaw blade guard should be in its lowest
q
position close to the bench during transport.
For miter cuts when the table is tilted, the parallel
q
stop must be positioned on the lower part of the
table.
When cutting round timber, use a suitable holding
q
device to prevent the workpiece turning.
Never use guards to lift or transport items.
q
Ensure that the bandsaw blade guards are used
q
and correctly adjusted.
Keep your hands a safety distance away from the
q
bandsaw blade. Use a push stick for narrow cuts.
The push stick has to be stored on the intended
q
device, so that it can be reached from normal
working position and is always ready to be used.
In the normal operating position the operator is
q
in front of the machine.
2.2 Personal protective equipment
It is mandatory to use:
Work gloves for handling materials and tools.
q
Protective glasses.
q
Headphones, caps, or noise-canceling helmet.
q
3.
TECHNICAL DATA
Rated voltage (U) ..................... 230 V~ 50 Hz
q
Rated power (P) .............................350 W S1
q
Weight ................................................16 kg
q
Band saw blade length .................... 1400 mm
q
No-load speed n0 .............................900/min
q
Throat size .......................................200 mm
q
Max. cut depth 45°/90° ..................50/80 mm
q
Max cut width ...................................200 mm
q
Blade length ................................... 1405 mm
q
Blade width .....................................6.35 mm
q
Blade thickness ..................................0.3 mm
q
Blade teeth .......................................... 6 TPI
q
Table tilt ............................................ 0°-45°
q
COMPA TECH S.r.l.
Web: www.compasaw.com - E-mail: info@compasaw.com
Tel. (+39) 059 527887 - Fax (+39) 059527889
- 22 -
Table size ................................ 300 x 300 mm
q
Sound pressure level (LpA) ........... 75.6 dB(A)
q
Sound power level (LWA) ..88.6 dB(A), K = 3.0
q
dB(A)
The noise levels were determined according to
the standards and regulations mentioned in the
declaration of conformity
3.1 Description of components
Unpack the appliance and check that everything is
present. Dispose of the packaging material properly.
Band saw with pre-assembled blade (140 cm)
q
Saw table
q
Push
q
Parallel guide
q
Mitre guide with angle adjustment
q
Allen key AF 3, 4, 5
q
Instruction manual
q
3.2 Function description
The band saw is a stationary saw with a motorized
band saw blade that is closed to form a loop. The
band saw allows precise cuts in wood and similar
materials.
Please refer to the descriptions below for information
on the operation of the operating elements.
3.3 Machine description
An illustration of the most important functional
components can be found on the front and the back
fold-out pages (Fig.A)
1. Thrust
2. Housing door
3. Tightening screw
4. Door lock
5. Blade guard
6. Saw table
7. Height adjustment
8. Securing screw
9. Sliding wheel adjustment
10. Locking nut
11. Frame
12. Tightening plate
