FLOWSIC550
Endress+Hauser
1
Device type
FL550
FLOWSIC550
2
Meter size
1
DN50 | 2"
2
DN80 | 3"
3
DN100 | 4"
4
DN150 | 6""
3
Meter length
A
50 mm [5.9]
B
171 mm [9.45]
C
241 mm [11.81]
D
300 mm [17.72]
4
Flange standard
1
PN40 (EN 1092-1)
2
PN63 (EN 1092-1)
3
ANSI300 (ASME B16.5)
4
ANSI600 (ASME B16.5)
5
Flange sealing surface
A
Type B, Form B1 (DIN EN 1092-1)
B
Raised faced, stock finished
6
Connection pressure sensor
2
1x plug NPT 1/4"
7
Connection temperature sensor
X
w/o
8
Material
1
LTCS
9
Material certificate
A
3.1
10
Coating / surface treatement
1
Company Standard
11
Transducer
A
Type 1 - H210
12
Qmax
3
650 m³/h [22 955 cfh]
4
1600 m³/h [56 503 cfh]
5
160 m³/h [5 650 cfh]
6
400 m³/h [14 125 cfh]
13
Qmin
A
2,5 m³/h [88 cfh]
C
6,5 m³/h [229 cfh]
D
4 m³/h [141 cfh]
E
16 m³/h [565 cfh]
F
22 m³/h [777 cfh]
G
53 m³/h [1 872 cfh]
Figure 38 : Codage des types (exemple)
14
Gas temperature /ambient temperature
1
-40...+70°C [-40... +158°F]
15
Sensors for EVC
A
w/o
B
p/T-Sensors external
16
Temperature Sensor
1
w/o
2
17
Pressure Sensor
A
w/o
B
absolut 0,8 ... 20 bar
C
absolut 7,0 ... 35 bar
D
absolut 14 ... 70 bar
E
absolut 25 ... 130 bar
F
relative 0 ... 70 bar [0... 1015 psi]
G
relative 0 ... 104 bar [0... 1500 psi]
18
Connectors /cable glands
1
3x NPT 1/2"
2
3x M20x1.5
19
Power supply
A
autarkic with battery pack (5Y)
B
external with backup (3 months)
20
Ex Certification
2
ATEX / IECEx / UKEx Zone 1, Group IIB
3
cCSAus Cl.I Div1
21
I/O
A
Standard 3x DO, 2x RS485
22
Conformity
1
PED
2
PED, MID
23
Bluetooth LE
A
w/o
24
RTU
1
w/o
25
Reserve
X
Reserve
M A N U E L D ' U T I L I S A T I O N
8030039/AE00/V1-1/2025-02
Annexes
71
