Thank you for choosing the Berger Titanium manoeuvring aid. This product has been manufac-
tured to high standards and has undergone careful quality control. With the help of the remote
control, you can effortlessly move your caravan to any desired position within the operating
guidelines.
Before you start assembling and operating the manoeuvring aid, please read these instructions
very carefully and observe all safety instructions! The owner of the caravan is always responsible
for correct use. Keep these instructions in your caravan for future reference.
These installation instructions apply to the manoeuvring aid Titanium. The manoeuvring aid
system consists of two 12 V motor rollers, a 12 V electronic control box and a remote control.
To function, the motor rollers must be pressed against the tyres of your caravan. The cross-
drive system allows you to engage the rollers of both drive units simultaneously. After that, the
manoeuvring aid is ready for use. You can use the remote control to move your caravan in any
direction.
The chassis clamps supplied with this system are suitable for installation on most standard ca-
ravan chassis with L or U profiles (Fig. 11). Please refer to Fig.13 for dimensions and clearances
BEFORE proceeding with installation.
Model number
Operating voltage
Average current consumption*
Maximum current consumption**
Speed
Approximate net weight (incl. all fixings and accesso-
ries)
Safe working load (SWL) Twin motor/square motor
Minimum width (caravan/trailer)
Maximum width (caravan/trailer)
Power source (caravan battery)
* Average power consumption when using a single-axle caravan of approx. 1100 kg on a hard, level surface.
** Maximum power consumption when using an approx. 1100 kg single-axle caravan on a slope of 1:4 (25%).
INTRODUCTION:
GUIDELINES FOR INSTALLATION
SPECIFICATION
EGO400
12 Volt direct current
25 amps (approx.)
76 amps (approx.)
12cm per sec. (approx.)
35 kg
2250Kg/3500Kg
1800 mm
2500mm
12V
