PACKAGE CONTENTS (FIG. A):
Quantity
Description
1
Motor unit (A)
1
Engine unit (B)
1
Main crossbar
1
Cross actuation centre bar
2
Cross actuation insert bars
1
Engaging tool
4
Classic Clamp - Stop Nut and Bolt*
2
Classic clamp - upper plate*
2
Classic clamp - U-plate*
2
Classic clamp - lower plate*
1
Cable ducts
2
Positive (+) Red motor cable
2
Negative (-) Black motor cable
1
Positive (+) Red battery cable
1
Negative (-) Black battery cable
8
Classic clamp - M10x55mm screw
8
Classic clamp - M10 Nyloc nut
8
Classic clamp - Ø10mm washer
20
M4x15mm P-Clip Screw
10
Cable P-Clips 19,2mm
10
Cable P-Clips 10,4mm
4
Battery terminal connector Ø8mm
4
Clamp ring connector Ø6mm
4
Clamp ring connector Ø4mm
3
Cable number markers (1,2,3,4)
3
Cable polarity markers (+,-)
4
Motor unit Cable tie 8x400
10
Cable tie 2x70
1
Battery disconnect switch (incl. key and fixings)
2
20mm roller spacers
