KUDO
MULTI-MODE WST
Rigging Procedures
VERSION 1.0
®
3. Install a second KUDO
it to the first one using two BLP.
Figure 37: Securing KUDO
5.
Attach the motor hook to the 18-shackle and raise the system so as to reach the array's bottom part.
6.
Slide out the lower rotating arm of the first KUDO
(with 10° angle setting).
7.
Raise the system to desired eighth.
6.3.2
Disassembling
Disassembling the flown horizontal array is carried out in the opposite order of how it was assembled by reversing the
order described in steps 1 through 7 of section 6.3.1 (pay attention to the warning sign).
KUDO_RM_ML_1.0
All manuals and user guides at all-guides.com
®
SYSTEM
enclosure and physically secure
®
#2 to KUDO
®
#1
®
enclosure. Attach the four lower BLP to secure the array
Figure 39: Securing the array's bottom part
w w w . l - a c o u s t i c s . c o m
4. Secure the 18-shackle to the KLIFT at the
chosen location (see appendix 9.2).
Figure 38: Installing the 18-shackle
26 en
