6.
Select the angle between the bottom KUDO
Note: Selecting the 5° angle sets the bottom KUDO
7. a. Place the KBUMP in position by aligning the stop tabs with the bottom KUDO
!
The KBUMP should be installed with the serial number tag oriented
towards the rear of the array.
Support the KBUMP in order to prevent it from falling.
WARNING
b. Attach the 4 BLP in the outer storage holes so as to secure the KBUMP to the bottom KUDO
KUDO_RM_ML_1.0
All manuals and user guides at all-guides.com
®
and the KBUMP.
®
Figure 23: Selecting the first enclosure angle
Figure 24: Placing the KBUMP onto the first KUDO
w w w . l - a c o u s t i c s . c o m
site angle parallel to the KBUMP (see also section 5.1).
®
front rigging points.
Inner storage hole
Outer storage hole
Stop tab
®
EN
®
enclosure.
19 en
