6.2
Ground stacking a vertical line source array (using KBUMP and KJACKx2)
Before installation, in order to position and correctly place the array the user should use L-ACOUSTICS
SOUNDVISION software to determine:
•
Number of KUDO
•
Angle between KBUMP and ground
•
Inter-angle between KUDO
•
Check of the system's mechanical conformity
Always refer to the mechanical data and warning indications provided in SOUNDVISION to verify
!
that safe system setup safety limits apply (see section ''Mechanical Data'' in the SOUNDVISION
software).
Ensure that KBUMP is physically secured to the stacking platform or subwoofer stack using ratchet
WARNING
straps or any applicable materials.
The rigging method to stack the KUDO
accessories. Attaching one element to the next is done by using fully integrated components unique to each KUDO
There is no need for any additional fastening accessory. Each KUDO
lock into the device above, and four rigging points that lock into the device below, using ball locking pins (BLP).
The following procedures describe how to stack a vertical KUDO
6.2.1
Stacking the KUDO
!
All along the following procedure systematically ensure that each BLP is correctly secured by pulling
on it.
WARNING
1.
Line up the KUDO
®
enclosures and the KBUMP structure at the stacking location.
Figure 20: KUDO
KUDO_RM_ML_1.0
All manuals and user guides at all-guides.com
®
enclosures
®
enclosures
®
system comprises the KBUMP and KUDO
®
array in the vertical position
®
and KBUMP at the stacking location
w w w . l - a c o u s t i c s . c o m
®
elements as well as the KJACK
®
enclosure incorporates two rotating arms that
®
line source array, and how to disassemble it.
®
EN
®
.
17 en
