11. For each KUDO

enclosure, remove both dolly board BLP by pulling on both lanyards.

12. On each KUDO

enclosure, connect the loudspeaker cables (refer to the ''KUDO

Secure the loudspeaker cables to the KBUMP.

For clarity purposes the loudspeaker cables will not be represented on the following figures.

IMPORTANT

6.1.2

Flying the KUDO

All along the following procedure, systematically ensure that each BLP is correctly secured by

pulling on it.

Ensure that no one is standing under or in close proximity to the system when it is being

raised in the air.

WARNING

Attach the motor hooks to the KBUMP shackles. Lift the KBUMP/first KUDO

KUDO_RM_ML_1.0

All manuals and user guides at all-guides.com

Figure 12: Pulling on the dolly board BLP lanyards

array in the vertical position

Figure 13: Raising the KBUMP/first KUDO

w w w . l - a c o u s t i c s . c o m

'' user manual).

assembly in the horizontal position.

assembly

13 en
