KUDO
MULTI-MODE WST
Rigging Procedures
VERSION 1.0
2. On each KUDO
®
enclosure, adjust the K-LOUVER
3. On each KUDO
®
enclosure, remove the 8 BLP.
4. On both sides of each KUDO
and secure the front rigging point using the dedicated BLP.
5. For each rotating arm on each KUDO
a. Manipulate the rotating arm to approx 10° to free the front rigging point.
b. Align the front rigging point and attach to next KUDO
Figure 22: Securing the front rigging points to the next KUDO
KUDO_RM_ML_1.0
All manuals and user guides at all-guides.com
®
SYSTEM
®
panels to the desired settings (see the ''KUDO
®
enclosure, push forward the rotating arm tab (accessible in the handle pocket)
Figure 21: Securing the front rigging points
®
enclosure:
®
a.
b.
w w w . l - a c o u s t i c s . c o m
enclosure.
®
®
'' user manual).
18 en
