6. Place the offset flange of the Base against the back
edge of the framed opening. In addition, align the back
edge of the side brackets with the back edge of the
framed opening. Secure the Blower & Base assembly
with the (9) 1" long drywall screws provided as shown
in Figure 6.
14 ½"
14 1/2"
OFFSET FLANGE
TOTAL WALL THICKNESS
TOTAL WALL THICKNESS
MINIMUM - 4"
MINIMUM - 4"
MAXIMUM - 12
MAXIMUM - 12 1/2""
42724-0-1120
All manuals and user guides at all-guides.com
14 ½"
14 1/2"
Figure 6
½
"
Figure 7
Empire Comfort Systems Inc. • Belleville, IL
7. Assemble (2) 6" diameter X 8" long collars with the collar
flanges as shown in Figure 8. Attach the flange to the
collar with (3) # 10 X ½" screws using the proper hole
locations based on the particular fireplace model you have.
NOTE: Collar Flange - Hand bend tabs to be bent down
DVCT SERIES
on DVLL72 only.
DVCT SERIES
DVCT SERIES
4"
4"
DVL(36,46)
DVL(36,46)
DVL(36,46)
3/8"
3/8"
8. Remove the (2) knockout holes on top of the fireplace
that are located to either side of the vent system. Use a
standard screwdriver and/or sheet metal snips to remove
these knockouts. See Figure 9. Both vent openings must
be used with the HMFA accessory.
REMOVE KNOCKOUTS & INSULATION
PLUGS PRIOR TO INSTALLING THE 6"
REMOVE KNOCKOUTS AND
DIAMETER COLLAR ASSEMBLIES
INSULATION PLUGS PRIOR TO INSTALLING
THE 6" DIAMETER COLLAR ASSEMBLIES
DVLL(36,48,60)
DVLL(36,48,60)
DVLL(36,48,60)
1"
1"
DVLL72
DVLL72
DVLL72
2"
2"
Figure 8
Figure 9
Page 7
